ASSMANN WSW 64-Way IDC Connector Female for Cable, 2 Row, 1A, 250V AC, Gold Plated Contacts AWP 64-7240-T

Free Delivery in India | Lowest Global Shipping Charges

ASSMANN WSW 64-Way IDC Connector Female for Cable, 2 Row, 1A, 250V AC, Gold Plated Contacts AWP 64-7240-T

Name: ASSMANN WSW 64-Way IDC Connector Female for Cable, 2 Row, 1A, 250V AC, Gold Plated Contacts AWP 64-7240-T
Brand: ASSMANN WSW
SKU: 208305
Price: 1.56 USD
Availability: InStock



Category IDC Connector Brand ASSMANN WSW Condition New

Specifications

Country of Origin	China
Voltage	250V ac
Brand	ASSMANN WSW
Orientation	Right Angle
Current	1A
Model	AWP 64-7240-T
Mount Type	Cable
Housing Material	Polybutylene Terephthalate
Contact Material	Brass
Series	AWP
Termination Type	IDC
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold over Nickel
Number of Contacts	64
Contact Gender	Female
Connector Gender	Female
Shrouded/Unshrouded	Shrouded

Key Features

Features 64 contact points arranged in 2 rows for high-density connections.
Rated for 1 amp current and 250V AC voltage suitable for various power applications.
Shrouded female connector with gold over nickel contact plating ensures durability and low resistance.
Constructed with brass contacts and a Polybutylene Terephthalate (PBT) housing providing robust mechanical and electrical performance.
Operates within a temperature range of -55°C to 105°C, supporting harsh industrial environments.
Termination type is insulation displacement contact (IDC) suitable for cable mounting with right-angle orientation.
Connector series AWP includes a central polarization feature to prevent mismating.
Ideal for industrial electronics, PCB connector assemblies, manufacturing automation, and control systems.

Product Description

ASSMANN WSW AWP 64-7240-T is a high-quality 64-way IDC female connector designed for cable mounting in electronic and industrial applications. This connector features a double-row configuration with a 2.54 mm pitch, enabling compact and efficient wiring solutions.

Equipped to handle 1 amp current at 250 volts AC, the connector is suitable for PCB connector assemblies, industrial automation, and manufacturing control systems where reliable electrical connections are essential.

The gold-plated contacts over nickel offer excellent conductivity and corrosion resistance. Its brass contact material paired with a Polybutylene Terephthalate housing rated UL94V-0 ensures mechanical robustness and flame retardance. The connector operates effectively across a wide temperature range from -55°C minimum to 105°C maximum, making it suitable for demanding environments.

The IDC termination type with right-angle orientation facilitates easy cable insertion and secure connection, while the shrouded and centrally polarized design prevents accidental mismating during assembly.

64 contacts arranged in 2 rows for high-density cable connections. Gold over nickel contact plating ensures durability and low contact resistance. Polybutylene Terephthalate housing provides flame resistance and mechanical protection.

Operates safely within industrial temperature ranges from -55°C to 105°C. Brass contacts offer reliable electrical performance. Right-angle cable mount with insulation displacement contact termination. Supports industrial, laboratory, manufacturing, and automation applications.

This product is ideal for professionals designing and assembling PCBs, cable harnesses, and other electrical wiring solutions requiring IDC Connectors with reliable performance and compact form factor.
