Amphenol Industrial SURLOK PLUS RADSOK EV Connector Male 200A, Crimp Termination, 1000V, IP67 SLPPB50BSB / C10-730188-100
Specifications
| Country of Origin | China |
|---|---|
| Brand | Amphenol Industrial |
| Colour | Black |
| Orientation | Right Angle |
| Current | 200A |
| Height | 75.6mm |
| Model | SLPPB50BSB / C10-730188-100 |
| Depth | 29mm |
| IP Rating | IP67 |
| Connector Type | RADSOK |
| Width | 21.6mm |
| Mount Type | Cable |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | SURLOK PLUS |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Pin Diameter | 8mm |
| Number of Rows | 1 |
| Wire size | 50mm² |
| Operating Voltage | 1000V |
| For Use With | SurLok 1-Position Receptacle |
| Standards/Approvals | UL 94-V0 |
| Number of Contacts | 1 |
| Contact Gender | Female |
| Connector Gender | Male |
| Better World Claim | Renewable Energy Solution |
| Amphenol Industrial, SURLOK PLUS RADSOK EV Connector Male, 200ABrand | Amphenol Industrial |
Key Features
- Compact and quick-mating design with 360° plug rotation.
- Features R4 Radsock technology for high tensile strength and conductivity.
- Crimp termination suitable for 50mm² wire size with 8mm pin diameter.
- Right angle orientation with spring locking and touch proof construction.
- Flame retardant thermoplastic housing rated to UL 94-V0 standard.
- Rated for operating temperatures from -40°C to 125°C.
- Suited for electric vehicle, rail mass transit, process control, and battery management applications.
- Environmentally sealed with IP67 ingress protection.
Product Description
Amphenol Industrial SLPPB50BSB / C10-730188-100 SURLOK PLUS RADSOK EV Connector Male 200A is engineered for robust and reliable high-current electrical connections in demanding industrial environments. Designed for use up to 1000 volts, this connector features a single row, one-contact design that terminates 50mm² cables with an 8mm pin diameter.
The connector is constructed with a copper alloy contact for excellent electrical conductivity and a thermoplastic housing rated to UL 94-V0 flame retardancy. Its right-angle cable mount design includes a spring locking mechanism and is keyed to prevent mismating, enhancing connection reliability. The connector plug allows 360° rotation and is touch proof, improving safety during installation and maintenance.
SurLok Plus RADSOK technology assures a high tensile strength and a reliable spring contact for secure mating connections. The environmental sealing provides IP67 rated ingress protection, ensuring resistance against dust and water, suitable for outdoor and industrial applications.
This product is commonly used in electric vehicle (EV/HEV) systems, rail mass transit, battery management systems (BMS), medical equipment, and process control industries. The connector supports renewable energy solutions, aligning with sustainable and efficient power systems.
Compact and quick mating Crimp style connector with 360° plug rotation. R4 RADSOK spring contact technology ensures superior tensile strength and conductivity. Rated for 200A current, 1000V operating voltage with IP67 environmental protection.
Durable thermoplastic housing with UL 94-V0 flame retardant rating for safety. Right angle orientation with keyed design to prevent mismating. Suitable for use with SurLok 1-Position Receptacle configurations. Operating temperature range from -40°C to 125°C supports harsh environment use.
Ideal for EV, rail, battery management, medical, and process control applications.
This Amphenol Industrial connector provides reliable, environmentally sealed power connections essential for modern industrial, automotive, and energy storage systems. Browse more from the EV Connectors category to find compatible and related products within the same high-performance SurLok Plus range.
