ASSMANN WSW 14-Way Shrouded IDC Connector Female for Cable, 2 Row, 3A Current, 250V AC, AWP 14-7240-T

ASSMANN WSW AWP 14-7240-T is a 14-way IDC connector female for cable applications, featuring a shrouded design with 2 rows of contacts suitable for reliable electronic connections. This IDC ribbon cable socket connector incorporates a 2.54 x 2.54mm pitch and supports a maximum current of 3A at 250V AC, making it ideal for industrial and electronic component interfacing.

The connector uses brass contacts plated with nickel and gold to ensure long-lasting conductivity and resistance to corrosion. Its housing is made from flame-retardant Polybutylene Terephthalate (PBT) material with UL94V-0 rating, ensuring safety and durability under demanding environmental conditions.

Designed with a right angle orientation, the connector is well suited for compact PCB designs where space saving is essential. Termination is IDC type, enabling fast, reliable cable assembly without soldering. The connector supports a wide operating temperature range from -40°C to 105°C, suitable for harsh environments in industrial manufacturing, electrical assemblies, automotive electronics, communication equipment, and other commercial applications.

This IDC connector from ASSMANN WSW belongs to the AWP series and assists in improving production efficiency by ensuring secure, high-quality wire connections. Its shrouded female IDC design provides added protection against accidental contact and enhances connector lifespan.

This IDC connector features 14 contacts arranged in 2 rows for efficient signal transmission. Supports a current rating of 3A and voltage up to 250V AC. The shrouded design ensures secure connection and protection against accidental contact.

Constructed with brass contacts plated in nickel and gold for durability and corrosion resistance. Housing is made of flame-retardant Polybutylene Terephthalate (PBT) with a UL94V-0 rating. Suitable for use in industrial, electronic, and communication equipment requiring robust cable interfacing.

Operates reliably in temperatures from -40°C to 105°C. Right angle orientation facilitates compact PCB layouts and wiring configurations. Termination type is IDC, enabling quick and secure cable assembly. Complies with series AWP design and does not carry specific standards or approvals.
