ASSMANN WSW 37-Way IDC Connector Male for Cable, 2 Row, 1A, 250V ac, Gold Nickel Tin Plating A-DSF 37LPIII/Z

Free Delivery in India | Lowest Global Shipping Charges

ASSMANN WSW 37-Way IDC Connector Male for Cable, 2 Row, 1A, 250V ac, Gold Nickel Tin Plating A-DSF 37LPIII/Z

Name: ASSMANN WSW 37-Way IDC Connector Male for Cable, 2 Row, 1A, 250V ac, Gold Nickel Tin Plating A-DSF 37LPIII/Z
Brand: ASSMANN WSW
SKU: 208261
Price: 4.13 USD
Availability: InStock



Category IDC Connector Brand ASSMANN WSW Condition New

Specifications

Country of Origin	China
Voltage	250V ac
Brand	ASSMANN WSW
Orientation	Straight
Current	1A
Model	A-DSF 37LPIII/Z
Mount Type	Cable
Housing Material	Polybutylene Terephthalate
Contact Material	Brass
Series	AD
Termination Type	IDC
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold, Nickel, Tin
Number of Contacts	37
Contact Gender	Male
Connector Gender	Male
Shrouded/Unshrouded	Shrouded

Key Features

The connector features 37 contacts arranged in 2 rows.
It is shrouded and designed for straight cable mounting.
Contact plating includes gold, nickel, and tin for enhanced conductivity and corrosion resistance.
The termination type is IDC for efficient cable assembly.
Operating temperature ranges from -55°C to 105°C, supporting a wide variety of environments.
Housing is made of durable polybutylene terephthalate ensuring mechanical stability.
Contact material is brass, offering good electrical performance.
Pitch between contacts is 2.54mm, conforming to standard spacing for PCB connectors.

Product Description

ASSMANN WSW A-DSF 37LPIII/Z is a high-quality 37-way IDC connector male type designed for cable mounting in various electronic applications. It features a two-row arrangement of contacts with a pitch of 2.54mm, suitable for PCB connections requiring precise spacing and secure cable termination.

This IDC connector supports a current rating of 1 ampere and an AC voltage of 250 volts, making it suitable for signal-level and low-power electronic uses. The connector is shrouded to ensure protected contact interfaces and is oriented straight for easy and reliable cable alignment during installation.

The connector termination uses insulation displacement contact technology, enabling efficient and reliable connection without the need for soldering, which improves manufacturing productivity. Contact plating with gold, nickel, and tin enhances resistance to corrosion while maintaining excellent electrical conductivity.

The durable housing is fabricated from polybutylene terephthalate, which provides strong mechanical support and long service life. Brass contact material is selected for its excellent electrical and mechanical properties.

Operating temperature range from -55°C to +105°C ensures this connector performs reliably across a broad spectrum of industrial environments and climatic conditions. It is a versatile component ideal for use in electronic manufacturing, industrial automation, instrumentation, and communication equipment assemblies.

This ASSMANN WSW IDC connector is made in China and does not list any specific industry certification or standard approvals, indicating it meets general commercial product requirements.

The connector has 37 contacts arranged in 2 rows. Rated for 1 ampere current and 250V AC voltage. Shrouded design with straight cable mount orientation. IDC termination type for easy cable installation. Contact plating includes gold, nickel, and tin for durability.

Housing material: Polybutylene terephthalate for robust construction. Contact material: Brass. Operating temperature range: -55°C to 105°C. Pitch between contacts: 2.54mm. Manufactured in China.

Use this connector for efficient and reliable cable terminations in industrial, electronic assembly, and manufacturing applications. Browse more IDC Connectors and related products on EnvMart for comprehensive electronic component solutions.
