Bourns Shielded Wirewound Surface Mount Inductor with Ferrite Core 22 μH ±30% 3 A Idc Q15 SRU1063A
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 10mm |
| Brand | Bourns |
| Height | 6.5mm |
| Length | 10mm |
| Model | SRU1063A |
| Depth | 10mm |
| Series | SRU1063A |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance Range | 4.7 to 100 Μh |
| Inductance | 22μH |
| Standards/Approvals | RoHS |
| Maximum DC Current | 3A |
| Maximum DC Resistance | 60mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 10MHz |
| Minimum Quality Factor | 15 |
| Inductor Construction | Shielded |
Key Features
- Shielded construction reduces magnetic radiation for low noise environments.
- Ferrite core enhances inductance stability and performance.
- Maximum DC resistance is 60 mΩ ensuring efficient current flow.
- Operating temperature ranges from -40°C to 125°C for reliability in harsh conditions.
- Minimum quality factor of 15 assures high efficiency in circuit applications.
- Moulded surface mount termination style for easy PCB assembly.
- Maximum self-resonant frequency of 10 MHz suits high-frequency applications.
- Series SRU1063A designed for automotive and industrial use.
Product Description
Bourns SRU1063A shielded wirewound surface mount inductor with ferrite core delivers 22 μH inductance with ±30% tolerance and can handle a maximum DC current of 3 amps. This inductor is designed primarily for automotive industry applications but is also suitable for consumer, industrial, medical, telecom, and other fields requiring high reliability and low magnetic interference.
The shielded construction minimizes magnetic radiation, making it ideal for low noise environments such as driver assistant devices, driver entertainment systems, DC-DC converters, and power supplies. The ferrite core material ensures stable inductance and enhanced performance across a wide operating temperature range from -40°C up to 125°C.
The SRU1063A series is AEC-Q200 qualified, guaranteeing automotive-grade quality and durability. This inductor features a low maximum DC resistance of 60 milliohms and a minimum quality factor of 15, enabling efficient current flow and high-frequency operation up to 10 MHz. It comes with moulded surface mount termination style for reliable mount on PCBs, and RoHS compliance ensures adherence to environmental regulations.
The compact form factor of 10 mm length, 10 mm diameter, and 6.5 mm height allows for dense PCB layout designs. Its design suits a variety of industrial applications including automotive electronics, power supplies, telecom equipment, and medical devices.
Shielded construction for low magnetic interference. Ferrite core for stable inductance. Maximum DC current rating of 3 A. Wide operating temperature: -40°C to 125°C. Low DC resistance at 60 mΩ. Minimum quality factor of 15 for high efficiency.
Surface mount termination. AEC-Q200 automotive qualification. Maximum self-resonant frequency of 10 MHz. RoHS compliant.
This Bourns SRU1063A inductor is suitable for demanding industrial, automotive, and telecom applications requiring durable, low-noise inductors with stable electrical characteristics. Explore more Surface Mount Inductors from this category at EnvMart for your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SRU1063A inductor has an inductance value of 22 μH with a tolerance of ±30%.
This model can handle a maximum DC current of 3 A.
The operating temperature range for this inductor is from -40°C to 125°C.
The maximum DC resistance is 60 mΩ, ensuring efficient current flow.
The maximum self-resonant frequency of the SRU1063A is 10 MHz, making it suitable for high-frequency applications.
It features a moulded surface mount termination style for easy assembly on PCBs.
The minimum quality factor is 15, which assures high efficiency in circuit applications.
Yes, this inductor is RoHS compliant, adhering to environmental regulations.
The inductor features a ferrite core and a shielded construction to minimize magnetic radiation.
The dimensions are 10 mm in length, 10 mm in diameter, and 6.5 mm in height.
This model is designed primarily for automotive applications but is also suitable for consumer, industrial, medical, and telecom fields.
The inductor is AEC-Q200 qualified, ensuring automotive-grade quality and reliability.
