Texas Instruments Precision Operational Amplifier 1 MHz Gain Bandwidth, 2 Channels, 8-Pin PDIP LT1013DIP
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 4.57mm |
| Length | 9.81mm |
| Model | LT1013DIP |
| Width | 6.35mm |
| Mount Type | Through Hole |
| Series | LT101 |
| Maximum Operating Temperature | 105°C |
| Package Type | PDIP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Pin Count | 8 |
| Maximum Supply Voltage | 30V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | -90 nA |
| Slew Rate | 0.4V/μs |
| Input Offset Current | 0.8 nA |
Key Features
- Designed for applications requiring low input offset voltage and low offset voltage drift with temperature.
- Features CMOS and JFET input types providing extremely low input bias currents.
- Operates with a supply voltage range from 5 V minimum up to 30 V maximum.
- Offers excellent stability with input offset voltage of 150 µV and input bias current of -90 nA.
- Suitable for demanding industrial and laboratory instrumentation requiring predictable operating characteristics.
- Operates reliably over a temperature range from -40°C to 105°C.
- Compact PDIP package measures 9.81 mm in length, 6.35 mm in width, and 4.57 mm in height.
- Gain bandwidth product of 1 MHz and a slew rate of 0.4 V/µs supports a variety of signal amplification tasks.
Product Description
Texas Instruments LT1013DIP precision operational amplifier offers a high-performance solution for advanced signal amplification needs in industrial, laboratory, and electronics applications.
This model features a dual-channel design packaged in a standard 8-pin PDIP, ideal for through-hole mounting and prototyping on PCBs. The device exhibits remarkably low input offset voltage (150 µV) and low offset voltage drift, ensuring consistent output under varying temperature conditions from -40°C to 105°C.
With a gain bandwidth product of 1 MHz and a slew rate of 0.4 V/µs, the LT1013DIP efficiently handles a wide range of amplification tasks, particularly where precision and stability are paramount.
The input bias current of -90 nA and input offset current of 0.8 nA make this amplifier suitable for high-impedance circuits requiring minimal current draw. This operational amplifier can operate with a supply voltage from 5 V to a maximum of 30 V, offering versatility across different power supply scenarios.
Designed for precision and low drift in demanding operational amplifier applications. Stable and predictable behavior ensures reliability in instrumentation and control systems. Compact PDIP package facilitates easy integration into various electronic designs.
Wide operating temperature range supports deployment in harsh environmental conditions. Low input bias and offset currents enhance performance in sensitive measurement circuits. Power supply range up to 30 V offers adaptability.
Ideal for industrial, laboratory, and electronic component use cases.
Explore more Operational Amplifiers from Texas Instruments and other high-quality semiconductor components on EnvMart to fulfill your electronics project and industrial application requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the LT1013DIP is 1 MHz, making it suitable for a variety of signal amplification tasks.
This operational amplifier operates with a supply voltage range from a minimum of 5 V to a maximum of 30 V.
The input offset voltage of this model is 150 µV, ensuring consistent output in various conditions.
It operates reliably over a temperature range from -40°C to 105°C, making it suitable for harsh environments.
The input bias current is -90 nA, which is beneficial for high-impedance circuits requiring minimal current draw.
The dimensions of this operational amplifier are 9.81 mm in length, 6.35 mm in width, and 4.57 mm in height.
The LT1013DIP features a dual-channel design, providing two channels for signal amplification.
The slew rate of the LT1013DIP is 0.4 V/µs, which supports efficient signal handling.
This model uses through-hole mounting, making it suitable for prototyping on PCBs.
The input offset current is 0.8 nA, which contributes to its precision in sensitive measurement applications.
The LT1013DIP comes in a standard 8-pin PDIP package, facilitating easy integration into electronic designs.
This model belongs to the LT101 series of operational amplifiers from Texas Instruments.
