Texas Instruments Operational Amplifier, JFET Input, 4-Channel, 3 MHz Gain Bandwidth, 15V SOIC TL074IDR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 8.65mm |
| Model | TL074IDR |
| Width | 3.91mm |
| Mount Type | Surface |
| Low Noise | 18nV/√Hz typical at 1 kHz |
| Series | TL074 |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Pin Count | 14 |
| Maximum Supply Voltage | 15V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 3MHz |
| Input Bias Current | 7 nA |
| Vos - Input Offset Voltage | 8 mV |
| Slew Rate | 13V/μs |
| Input Offset Current | 2 nA |
| Wide supply voltage range | ±5 to ±15V |
| High Slew Rate | 13 V/μs typical |
| Low Total Harmonic Distortion | 0.003% typical |
Key Features
- Features four independent operational amplifier channels for versatile circuit design.
- Operates over a supply voltage range from 5V to 15V to suit various electronic applications.
- Low input bias current of 7 nA ensures minimal signal distortion and high precision.
- High slew rate of 13 V/μs and low total harmonic distortion (0.003%) provide excellent signal fidelity.
- Compact 14-pin SOIC surface mount package measuring 8.65 mm length by 3.91 mm width and 1.58 mm height.
- Wide operating temperature range from -40°C to 85°C supports robust industrial usage.
- Ideal for audio signal processing, instrumentation, and other precision amplification tasks.
Product Description
Texas Instruments TL074IDR is a quad operational amplifier featuring JFET input stages, offering low noise, low distortion, and high slew rates suited for precision analog circuit applications. This device operates over a wide supply voltage range from ±5V to ±15V, making it adaptable for multiple power configurations.
Designed for surface mount assembly, the TL074IDR comes in a 14-pin SOIC package with dimensions of 8.65 mm length, 3.91 mm width, and 1.58 mm height, optimizing PCB space utilization. The amplifier boasts a gain bandwidth product of 3 MHz and a slew rate of 13 V/μs, ensuring high-speed response and accurate signal reproduction.
Key electrical parameters include an input bias current of 7 nA, input offset voltage of 8 mV, and input offset current of 2 nA, delivering precise signal amplification with minimal errors. The typical low noise level of 18 nV/√Hz at 1 kHz, combined with low total harmonic distortion of 0.003%, suits audio and instrumentation environments requiring high signal integrity.
Operating temperature range from -40°C to 85°C ensures reliability in harsh industrial and commercial applications. This op amp does not conform to automotive standards but is ideal for laboratory instrumentation, audio equipment, signal processing, and other electronic projects requiring multi-channel amplification.
The TL074IDR package supports four independent amplifiers, allowing designers to implement complex circuits efficiently. Features four independent operational amplifier channels for versatile circuit design. Operates over a supply voltage range from 5V to 15V to suit various electronic applications.
Low input bias current of 7 nA ensures minimal signal distortion and high precision. High slew rate of 13 V/μs and low total harmonic distortion (0.003%) provide excellent signal fidelity. Compact 14-pin SOIC surface mount package measuring 8.65 mm length by 3.91 mm width and 1.58 mm height.
Wide operating temperature range from -40°C to 85°C supports robust industrial usage. Ideal for audio signal processing, instrumentation, and other precision amplification tasks. Explore the full range of Operational Amplifiers and electronic components in the Electronics & Electricals category at EnvMart to meet your design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the TL074IDR is 3 MHz, which supports high-speed response in various applications.
This model operates over a supply voltage range from ±5V to ±15V, making it suitable for various power configurations.
The TL074IDR features four independent operational amplifier channels, allowing for versatile circuit design.
The TL074IDR comes in a compact 14-pin SOIC package measuring 8.65 mm in length, 3.91 mm in width, and 1.58 mm in height.
The input bias current for the TL074IDR is 7 nA, which helps ensure minimal signal distortion and high precision.
This model operates within a wide temperature range from -40°C to 85°C, making it suitable for robust industrial usage.
The TL074IDR has a high slew rate of 13 V/μs, which contributes to its ability to handle fast signal changes effectively.
The TL074IDR has a low total harmonic distortion of 0.003% typical, ensuring excellent signal fidelity in audio applications.
The input offset voltage for this operational amplifier is 8 mV, which aids in achieving precise signal amplification.
This operational amplifier is designed for surface mount assembly, optimizing PCB space utilization.
The TL074IDR is ideal for applications in audio signal processing, instrumentation, and other precision amplification tasks.
The typical low noise level of the TL074IDR is 18 nV/√Hz at 1 kHz, making it suitable for high signal integrity environments.
