Panasonic PCB Power Relay, 5V dc Coil, 16A Switching Current, SPST ADW1105HLW

Panasonic ADW1105HLW PCB Power Relay is designed for industrial and commercial applications requiring high switching capacity with compact footprint. This relay operates on a 5V dc coil voltage and supports a switching current of up to 16A with SPST contact configuration, making it suitable for power control in electrical circuits and automation systems.

The relay incorporates a coil resistance of 125Ω and consumes a coil power of 200mW, offering energy-efficient operation. Rated for a maximum switching AC voltage of 277V ac and a switching power of 4.4kVA, it is capable of handling demanding load conditions.

With an operating temperature range from -40°C to 70°C, the relay ensures stable performance under varying environmental conditions. Its silver alloy contact material provides durability and excellent electrical conductivity, while a low contact resistance of 100mΩ minimizes energy loss.

Compact dimensions of 24mm length, 15.8mm height, and 10mm width allow easy integration into PCB layouts. The mount type is PCB with PCB pin terminals, facilitating secure and reliable connections.

This relay series meets multiple international standards and approvals including cUL, cULus, UL, VDE, CSA, and PTI 325V, ensuring compliance with global safety and quality requirements.

Common applications include use in appliances, lighting controls, smart meters, power supplies, refrigerators, and washing machines across industries such as industrial automation, energy, and white goods manufacturing.

This Panasonic ADW1105HLW relay combines reliability, efficiency, and versatility for diverse industrial, laboratory, HVAC, and commercial electrical control systems. Compact and robust design suitable for high operating power applications.

Features a coil resistance of 125Ω and coil power of 200mW. Maximum switching AC voltage of 277V ac and switching power of 4.4 kVA. Operational temperature range from -40°C to 70°C ensuring reliable performance. Constructed with silver alloy contact material for excellent conductivity.

Mount type is PCB with PCB pin terminals, ideal for printed circuit boards. Dimensions: 24mm length, 15.8mm height, and 10mm width for easy integration. Low contact resistance of 100mΩ improves efficiency and reduces losses.

Certified and compliant with standards including cUL, UL, VDE, CSA, and PTI 325V. Manufactured in Thailand, assuring quality and reliability. Explore the full range of Power Relays and related electrical components on EnvMart for reliable industrial and commercial automation solutions.
