Panasonic PCB Power Relay 12V dc Coil 16A Switching Current SPST ADW1212HTW
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 18.8mm |
| Length | 24mm |
| Model | ADW1212HTW |
| Width | 10mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | ADW1 |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 16A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | CSA, cUL, cULus, IEC 60335-1, PTI 325V, TV-8, UL, VDE |
| Coil Resistance | 360Ω |
| Coil Voltage | 12V dc |
| Switching AC Voltage | 277V ac |
| Coil Power | 400mW |
Key Features
- The relay operates with a coil voltage of 12V dc ensuring precise control.
- It supports a maximum switching AC voltage of 277V ac, suitable for various electrical applications.
- The device features a compact design with dimensions of 24mm length, 10mm width, and 18.8mm height.
- Operating temperature range from -40°C to 70°C allows versatile and robust performance.
- The relay contacts are made of a durable silver alloy providing reliable electrical conductivity.
- It utilizes a PCB mounting type with PCB pin terminals for easy integration.
- Coil resistance is specified at 360 ohms with a coil power consumption of 400mW.
- High contact switching power of 4.4 KVA enhances performance under load conditions.
Product Description
Panasonic ADW1212HTW PCB Power Relay is a high-quality polarized power relay designed for demanding industrial and commercial applications. Featuring a 12V DC coil and a single-pole single-throw (SPST) contact configuration, it ensures seamless switching of up to 16A current at 277V AC.
This relay supports operation across a wide temperature spectrum from -40°C to 70°C, which makes it ideal for use in robust environments such as appliance controls, lighting systems, smart meters, and industrial machinery.
The compact size (24mm long, 10mm wide, 18.8mm high) allows convenient PCB mounting using its PCB pin terminals. Silver alloy contacts guarantee reliable and low resistance (100mΩ) switching performance, while the coil resistance of 360Ω and coil power of 400mW contribute to energy-efficient operation under continuous use.
Built with compliance to multiple safety and performance standards including CSA, cUL, UL, VDE, and IEC 60335-1, this relay ensures robust and safe performance in diverse industrial, lighting, and appliance applications.
The relay can run at a high operating temperature ensuring durability. The compact size fits well in PCB-mounted circuits with limited space. Highly reliable switching with silver alloy contact materials. Suitable for lighting control, smart metering, power supplies, refrigerators, and washing machines.
Industry applicability includes appliances and white goods, industrial, energy, and lighting sectors.
Panasonic's ADW1212HTW power relay is engineered to provide long-term reliable switching performance under challenging conditions, making it a valuable component in industrial automation, HVAC systems, and commercial electrical installations.
Explore more quality Power Relays and electrical components from Panasonic available in the EnvMart catalog to meet your application-specific requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay supports a maximum switching current of 16A.
This model operates with a coil voltage of 12V DC.
The dimensions of the relay are 24mm in length, 10mm in width, and 18.8mm in height.
It features a single-pole single-throw (SPST) contact configuration.
The relay can switch a maximum AC voltage of 277V.
The relay contacts are made of a durable silver alloy, ensuring reliable electrical conductivity.
It operates within a temperature range of -40°C to 70°C.
The coil resistance is specified at 360 ohms.
The coil power consumption is 400mW.
This model utilizes PCB mounting with PCB pin terminals for easy integration.
It complies with multiple standards including CSA, cUL, UL, VDE, and IEC 60335-1.
It is suitable for various applications including appliance controls, lighting systems, smart meters, and industrial machinery.
