Hirose DF3 Series Straight Surface PCB Header, 4 Contact(s), 2 mm Pitch, 1 Row, Shrouded DF3EA-4P-2V(21)
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 250V |
| Brand | Hirose |
| Orientation | Straight |
| Current | 3A |
| Model | DF3EA-4P-2V(21) |
| Mount Type | Surface |
| Housing Material | Polyamide |
| Contact Material | Brass |
| Series | DF3 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Tin |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
Key Features
- Features a low profile design for compact PCB applications.
- Includes a friction locking mechanism ensuring secure mating connections.
- Equipped with PCB mounting bosses for precise positioning during soldering.
- Reinforced metal fittings provide strong attachment to the PCB preventing joint peeling.
- Constructed from polyamide housing material with brass contacts plated with tin.
- Supports a current rating of 3A and voltage up to 250V.
- Operates reliably between -55°C to 105°C.
- Compatible with board-to-board and wire-to-board connector systems.
Product Description
Hirose DF3EA-4P-2V(21) is a series of straight surface mount PCB headers featuring 4 contacts with a 2 mm pitch and a single row configuration in a shrouded polyamide housing. This connector integrates a low profile design, making it well suited for compact electronic devices.
The friction locking mechanism ensures a secure reliable mating connection with the DF3 socket, enhancing stability in both board-to-board and wire-to-board systems. Equipped with PCB mounting bosses, it facilitates accurate positioning on the PCB during soldering procedures. Reinforced metal fittings on either side of the housing add mechanical strength by securing the connector firmly to the PCB, preventing peeling at the solder joint areas.
Constructed with brass contact material plated in tin, it supports a maximum current of 3 amps and a voltage rating of 250 volts. The device performs stably over a wide temperature range from -55°C up to 105°C, making it suitable for demanding industrial and commercial electronics applications.
The Hirose DF3 series connectors are widely utilized in business equipment such as copy machines and printers, providing reliable electrical connections with durable mechanical properties. Its solder termination type and male contact gender allow for straightforward insertion and secure attachment to circuit boards.
Low profile design for space-saving PCB layouts. Friction locking mechanism for secure connector mating. PCB mounting bosses aid precise positioning during soldering. Reinforced metal fittings secure the connector to prevent joint damage.
Polyamide housing with brass contacts and tin plating. Rated current of 3A and voltage rating of 250V. Operational temperature range from -55°C to 105°C. Compatible with board-to-board and wire-to-board systems. Solder termination with male contact gender.
Appropriate for business equipment like printers and copiers.
This PCB Header is manufactured in Japan, ensuring high quality standards. It is a reliable component choice for industrial, commercial, and manufacturing electronics assembly requiring robust and accurate connector solutions.
Explore more Hirose brand PCB connectors and related electronic components at EnvMart to meet diverse technical requirements effectively.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current of 3A and a voltage rating of 250V.
It operates reliably within a temperature range of -55°C to 105°C.
The housing is made from polyamide, while the contacts are brass plated with tin.
This PCB header features 4 contacts with a pitch of 2 mm.
Yes, it is compatible with both board-to-board and wire-to-board connector systems.
It uses a solder termination type with male contact gender.
This model has a straight orientation and a single row configuration.
It includes a friction locking mechanism that ensures secure mating connections, enhancing stability.
This PCB header is designed for surface mounting, but specific dimensions are not provided in the data.
This PCB header is manufactured in Japan, ensuring high quality standards.
It is widely utilized in business equipment such as printers and copiers.
It is equipped with PCB mounting bosses for precise positioning during soldering, enhancing installation accuracy.
