KEMET R82 Film Capacitor, 680 nF, ±10 % Tolerance, 63 V DC, 40 V AC, Radial Leaded, 5 mm Pitch R82DC3680Z360K

KEMET R82DC3680Z360K Film Capacitor is a high-quality electronic component featuring 680 nF capacitance with ±10 % tolerance. It is rated for 63 V DC and 40 V AC, making it suitable for demanding applications such as timing, oscillator circuits, blocking, coupling, and decoupling in automotive and industrial electronics.

This capacitor belongs to the R82 series, comprising metallised polyester film capacitors with radial leads of tinned wire electrically welded to ensure reliable connections. The capacitor winding is encased in a self-extinguishing, solvent-resistant plastic case made from thermosetting resin material, enhancing durability and safety in various environments.

The radial lead pitch is 5 mm with lead length of 17 mm and diameter of 0.6 mm, enabling easy PCB mounting. Its compact form factor measures 9.5 mm in height, 7.2 mm in length, and 4.5 mm in width, making it suitable for space-constrained circuit designs.

Designed to operate efficiently within a temperature range of -55°C to +105°C, this capacitor complies with automotive AEC-Q100 standards ensuring robustness and reliability for automotive and other industrial applications. It meets RoHS directives and IEC 60384-2 standards for safety and environmental compliance.

This film capacitor features a radial leaded design with 5 mm lead pitch. Constructed with metallised polyester film and self-extinguishing plastic case. Operates reliably in temperature ranges from -55°C to +105°C. Meets automotive AEC-Q100 standards for quality and reliability.

Suitable for blocking, coupling, decoupling, and oscillator circuit applications. Encapsulated with thermosetting resin for solvent resistance and durability. Lead length is 17 mm with lead diameter of 0.6 mm for secure connections.

Complies with RoHS and IEC 60384-2 standards. Compact dimensions: 9.5 mm height, 7.2 mm length, and 4.5 mm width. Packaged in a protective bag to ensure safe transport and storage.

This capacitor is widely used in industrial electronics, automotive circuits, consumer electronics, and other electrical devices requiring stable film capacitors with moderate voltage and capacitance ratings. Its reliable construction and quality certifications make it ideal for advanced circuit design and manufacturing.
