KEMET R82 Film Capacitor, 15 nF, ±5 % Tolerance, 100 V dc, 63 V ac, Through Hole Mount R82EC2150DQ50J

KEMET R82EC2150DQ50J is a high-quality film capacitor with a capacitance of 15 nF and tight tolerance of ±5 %. It supports a rated DC voltage of 100 V and an AC voltage of 63 V, featuring a through hole mounting style that enables secure PCB installation. This capacitor belongs to the R82 series, manufactured with metallised polyester film and radial tinned wire leads electrically welded to the contact metal layer. Its compact dimensions (7.2 mm length, 6.5 mm height, and 2.5 mm width) make it suitable for space-constrained circuits.

The robust encapsulation uses self-extinguishing, solvent-resistant plastic combined with thermosetting resin materials, ensuring operational safety. It complies with IEC 60384-2 and RoHS directives alongside automotive grade AEC-Q100, making it ideal for automotive and industrial applications requiring reliability and compliance.

Typical applications encompass blocking, coupling, decoupling, timing, and oscillator circuits where consistent capacitance and stability under temperature ranges from -55°C to +105°C are crucial. The 5 mm lead pitch and 0.5 mm lead diameter facilitate straightforward PCB integration.

With an ammo pack packaging style, the capacitor supports efficient automated assembly processes. The R82 series capacitors also incorporate self-healing technology, enhancing reliability in harsh environments.

The capacitor features metallised polyester film construction with radial leads. It offers a lead pitch of 5 mm and is packaged in ammo pack format. Rated for a maximum operating temperature of 105°C and a minimum of -55°C.

Complies with IEC 60384-2, RoHS standards and automotive standard AEC-Q100. Lead diameter is 0.5 mm with lead length of 18.5 mm ensuring easy PCB mounting. Typical uses include blocking, coupling, timing, oscillator circuits, and decoupling in electronic designs.

Encapsulated in a solvent-resistant plastic case with thermosetting resin for durability and safety.

This Film Capacitor is widely used in industrial electronics, automotive systems, manufacturing equipment, and HVAC controls among other applications that demand durable and compliant passive electronic components.
