STMicroelectronics 4-Element Uni-Directional TVS Diode 300W, 6-Pin SOT-23 ESDA14V2SC6
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.3mm |
| Length | 3.05mm |
| Model | ESDA14V2SC6 |
| Width | 1.75mm |
| Mount Type | Surface |
| Series | ESDAxxSCx |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 6 |
| Number of Elements per Chip | 4 |
| Diode Configuration | Common Anode |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 14.2V |
| Maximum Reverse Stand-off Voltage Vwm | 12V |
| Peak Pulse Power Dissipation Pppm | 300W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 14A |
| Maximum Reverse Leakage Current | 5μA |
Key Features
- The device features a uni-directional diode configuration with a common anode for efficient transient voltage suppression.
- It supports a peak pulse power dissipation of 300 W, making it suitable for handling high energy bursts.
- Manufactured in a compact 6-pin SOT-23 package, enabling easy surface mounting on PCBs.
- Operates within a voltage range of 12V maximum reverse stand-off voltage and 14.2V minimum breakdown voltage to protect downstream components effectively.
- Designed with four elements per chip to provide enhanced protection capabilities.
- Has a low leakage current under 20mA max at breakdown voltage ensuring minimal power loss during normal operation.
- Meets operating temperature specifications from -40°C to 125°C for reliable performance in diverse environments.
- Suitable for use in electronic, power, and semiconductor applications requiring robust transient suppression and ESD protection.
Product Description
STMicroelectronics ESDA14V2SC6 is a 4-element uni-directional transient voltage suppressor (TVS) diode designed to protect sensitive electronic circuits from electrostatic discharge (ESD) and voltage surges. It is housed in a compact 6-pin SOT-23 surface mount package, making it ideal for space-constrained applications.
This diode array offers a peak pulse power dissipation capability of 300 watts, enabling it to safely absorb high energy transient events and safeguard connected semiconductor devices. The common anode configuration and uni-directional design provide effective voltage clamping during surge events, protecting downstream circuitry.
The ESDA14V2SC6 operates reliably over a wide temperature range from -40°C to 125°C, making it suitable for automotive, industrial, and commercial electronic environments. It features a maximum reverse stand-off voltage of 12 volts and a minimum breakdown voltage of 14.2 volts, with a low leakage current of less than 20mA at breakdown, ensuring efficiency in normal operating conditions.
Applications include transient surge protection in power supplies, communications equipment, and consumer electronics requiring robust ESD protection. The compact SOT-23 package supports automated PCB assembly and reduces board space requirements.
The device incorporates 4 diode elements per chip for enhanced protection versatility. Low leakage current characteristics minimize power loss and heat generation. Compatible with standard SMT assembly for ease of integration.
STMicroelectronics brand assures quality and reliability in semiconductor components. Ideal for ESD protection in sensitive electronic circuits across industrial and commercial sectors.
This product is listed under the TVS Diode category to assist buyers in searching specialized discrete semiconductor devices for transient voltage suppression. Explore other semiconductor protection components within this EnvMart category for various applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ESDA14V2SC6 has a peak pulse power dissipation capability of 300 watts, allowing it to absorb high energy transient events effectively.
The maximum reverse stand-off voltage for the ESDA14V2SC6 is 12 volts, which helps in protecting downstream components from voltage surges.
The minimum breakdown voltage of the ESDA14V2SC6 is 14.2 volts, ensuring effective clamping during surge events.
This model operates reliably within a temperature range of -40°C to 125°C, suitable for various environments.
The ESDA14V2SC6 features a common anode configuration with a uni-directional design, which allows for effective transient voltage suppression.
This diode array contains four elements per chip, providing enhanced protection capabilities against voltage transients.
The dimensions of this model are 3.05mm in length, 1.75mm in width, and 1.3mm in height, making it suitable for compact applications.
The maximum reverse leakage current for the ESDA14V2SC6 is 5μA at breakdown voltage, ensuring minimal power loss during operation.
This model supports surface mounting, making it easy to integrate into printed circuit boards (PCBs).
It is suitable for transient surge protection in power supplies, communications equipment, and consumer electronics requiring robust ESD protection.
The test current for this model is 1mA, which is used to evaluate its performance under specified conditions.
The maximum peak pulse current for the ESDA14V2SC6 is 14A, allowing it to handle significant transient events safely.
