TE Connectivity 2-Way Shrouded Female IDC Connector for Cable 600V AC 7A 3.96mm Pitch MTA-156 3-640427-2
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V ac |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 7A |
| Mount Type | Cable |
| Housing Material | Nylon |
| Contact Material | Copper |
| Series | MTA-156 |
| Termination Type | IDC |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 2 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shrouded/Unshrouded | Shrouded |
| Connector,PCB,MTA,2 way,cable socket,3.96mm pitch,22 awgBrand | TE Connectivity |
Key Features
- This IDC connector accommodates 2 female contacts for secure electrical connection.
- Rated for 7 amperes current and 600 volts AC voltage.
- Features a shrouded design with right angle orientation and cable mount type.
- Constructed with copper contacts plated with tin over nickel and housed in durable nylon material.
- Operating temperature range from -55°C to 105°C ensures reliability in harsh environments.
- Compatible with stranded wire sizes from 18 to 26 AWG using insulation displacement contact technology.
- MTA-156 series allows quick assembly without wire stripping, saving labor and time.
- Connector equipped with locking ramp and polarization tabs to prevent reverse mating.
Product Description
TE Connectivity 3-640427-2 2-Way Shrouded Female IDC Connector is designed for cable termination applications requiring reliable and efficient wire-to-wire or wire-to-board connections. It belongs to the MTA-156 series featuring a 3.96mm pitch and supports stranded wire sizes from 18 to 26 AWG using insulation displacement contact (IDC) technology. The connector is constructed with copper contacts plated with tin over nickel housed in nylon 6/6 UL94V-2 rated material for durability and electrical safety.
This IDC connector is rated for 7 amperes current and 600 volts AC voltage, making it suitable for power and signal transmission in various industrial, commercial, and electronic assemblies. The shrouded female connector has a right angle orientation and mounts to cable, providing robust mechanical retention with locking ramps and polarization tabs to avoid incorrect mating.
The operating temperature range from -55°C to 105°C ensures stable performance in challenging environments, including industrial and manufacturing setups. Using the IDC technology allows quick assembly without the need to strip wires, improving manufacturing throughput and reducing errors.
2 female contacts with 1 row configuration for compact design. Shrouded housing to protect contacts and prevent accidental shorts. Locking ramp and polarization tabs for secure, foolproof connections. Matte tin plating for corrosion resistance and reliable conductivity.
Nylon housing material provides mechanical strength and flame retardance. Suitable for wire sizes 18 to 26 AWG, facilitating flexible use cases. Specifically designed for MTA-156 3.96mm pitch interconnect system. Widely used in electronic components, power connectors, and PCB applications.
This TE Connectivity IDC Connector is an essential component for engineers and technicians requiring high-quality connectors for electrical assemblies in industrial, manufacturing, and laboratory environments. It optimizes assembly efficiency and reliability with standardized specifications and robust material construction.
Explore more TE Connectivity products and related electrical connectors in the Electronics & Electricals category at EnvMart for your project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This IDC connector is rated for a current of 7 amperes.
It is rated for a maximum voltage of 600 volts AC.
The pitch size of this connector is 3.96mm.
It is compatible with stranded wire sizes from 18 to 26 AWG.
The operating temperature range is from -55°C to 105°C.
The connector features copper contacts plated with tin over nickel and a housing made of nylon.
This model has a cable mount type for installation.
It is equipped with locking ramps and polarization tabs to prevent reverse mating.
This IDC connector has 2 female contacts.
The connector has a right angle orientation.
The termination type for this connector is insulation displacement contact (IDC).
The connector is manufactured in India.
