ROHM 3 Digit 7 Segment LED Display Anode Red 16mcd Right Side 14.2mm LB-603VF

Free Delivery in India | Lowest Global Shipping Charges

ROHM 3 Digit 7 Segment LED Display Anode Red 16mcd Right Side 14.2mm LB-603VF

Name: ROHM 3 Digit 7 Segment LED Display Anode Red 16mcd Right Side 14.2mm LB-603VF
Brand: ROHM
SKU: 196066
Price: 9.95 USD
Availability: InStock



Category LED Displays Brand ROHM Condition New

Specifications

Country of Origin	China
Display Type	7 Segment
Brand	ROHM
Model	LB-603VF
Mount Type	Through Hole
Series	LB-603 FP
Character height	14.2mm
Maximum Operating Temperature	75°C
Minimum Operating Temperature	-25°C
Number Of Segments	7
External Width	37.5mm
External Depth	8mm
External Height	18mm
Power Dissipation	960mW
Luminous Intensity	16mcd
Standards/Approvals	RoHS
LED Colour	Red
Dominant Wavelength	650nm
Colour of Face	Black
Forward Voltage	2V
Forward Current	15mA
Number of Characters	3
Character Width	8mm
Common Connection	Anode
Decimal Orientation	Right Side
LB-603MF ROHM 3 Digit 7-Segment LED Display, CA Green 25 mcd RH DP 14.2mmBrand	ROHM

Key Features

Three-digit numeric display with high contrast black surface.
Through hole mount type for easy assembly.
Dominant wavelength of 650nm ensures clear and vivid red display.
Wide operating temperature range from -25°C to 75°C.
Low forward voltage of 2V to reduce power consumption.
Power dissipation of 960mW suitable for efficient operation.
Common anode connection type for compatibility with standard circuits.
Compact size with external dimensions of 37.5mm width, 18mm height, and 8mm depth.

Product Description

ROHM LB-603VF 3 Digit 7 Segment LED Display is a high quality electronic component designed for numerical display applications. It features three red 7-segment digits with a luminous intensity of 16mcd, providing clear visibility in various lighting conditions. The display is constructed with a black face color to enhance contrast and readability.

This product uses a common anode configuration and is mounted through hole, making it compatible with a wide range of printed circuit boards. The character height of 14.2mm and width of 8mm allow for compact display modules, ideal for industrial, laboratory, and consumer electronic devices. The decimal point is positioned on the right side for standard numeric representations.

The display operates efficiently at a forward voltage of 2V and forward current of 15mA, with power dissipation up to 960mW. It can function reliably across a temperature range from -25°C to 75°C, suitable for a variety of environmental conditions.

Its external dimensions are 37.5mm in width, 18mm in height, and 8mm in depth, allowing for easy integration into custom display panels and instrumentation. The LB-603VF series complies with RoHS standards, ensuring environmental safety and regulatory compliance.

Three-digit numeric display with high contrast black surface. Through hole mount type for easy assembly. Dominant wavelength of 650nm ensures clear and vivid red display. Wide operating temperature range from -25°C to 75°C.

Low forward voltage of 2V to reduce power consumption. Power dissipation of 960mW suitable for efficient operation. Common anode connection type for compatibility with standard circuits. Compact size with external dimensions of 37.5mm width, 18mm height, and 8mm depth.

Manufactured in China with RoHS compliance.

This LED display is ideal for use in industrial instrumentation, electronic measurement devices, consumer electronics, and educational equipment. Its durable construction and efficient operation make it suitable for manufacturing, laboratory, and HVAC control systems requiring numerical output.

Explore more electronic components and LED display solutions on EnvMart for your next project or production line enhancement.
