TE Connectivity AMPMODU HV100 Series Straight Surface PCB Socket, 4-Contact, 2 Row, 2.54 mm Pitch, 12A, 250V HV100

TE Connectivity HV100 Series Straight Surface PCB Socket (Model: HV100) is a high-quality, 4-contact, 2-row PCB socket designed for surface mounting applications with a precise 2.54 mm pitch. This socket is part of the AMPMODU HV100 series, recognized for reliable board-to-board electrical connections in varied industrial and commercial electronic assemblies.

Engineered to handle up to 12 amps of current and support voltages up to 250V, the socket utilizes a polyamide housing material that provides excellent mechanical strength and heat resistance suitable for operation in harsh environments ranging from -65°C to 125°C. The bronze contacts plated with tin ensure stable signal transmission with corrosion resistance, while the female contact gender allows compatible mating with appropriate connectors.

The straight orientation and surface mount type simplify PCB integration and support top or bottom entry, combined with an end stackable design, making it a flexible option for complex electronic assemblies. Its connector system is optimized for board-to-board interfacing with consistent performance and durability.

Typical industrial and laboratory applications include electronic instrumentation, circuit board assemblies, telecommunications, and other manufacturing operations requiring dependable PCB Sockets that sustain rigorous environmental and electrical demands. The HV100 series offers modular interconnect solutions adhering to the industry-standard 2.54 mm grid pitch for universal adoption.

Supports a current rating of 12A for robust electrical performance. Designed for surface mounting with a straight orientation for PCB integration. Constructed with polyamide housing for durability and heat resistance. Features bronze contact material with tin plating for corrosion resistance.

Operates reliably in temperatures ranging from -65°C to 125°C. Connector system supports board-to-board connections with a 2.54 mm row pitch. Termination via solder ensures secure and stable electrical contacts. Female contact gender socket strip in a 2-row configuration for versatile use.
