XP Power High-Voltage DC/DC Converter 200V Output, 2000V Peak, 15.5V DC Input, 5 mA Output Current, 1 W Power CA12N
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power CA DC/DC Converter, 200V, 2000 V/, 15 |
| Brand | XP Power |
| Length | 44.45mm |
| Model | CA12N |
| Depth | 0.50in |
| Gross Weight | 39.6g |
| Width | 27.94mm |
| Mount Type | Chassis |
| Series | CA |
| Maximum Operating Temperature | 50°C |
| Package Type | Miniature Shielded Case |
| Minimum Operating Temperature | -10°C |
| MTBF | 2100000h |
| Number of outputs | 1 |
| Ripple and Noise | 0.0005% Pk-Pk |
| Maximum Output Power | 1W |
| Maximum Input Voltage | 15.5V dc |
| Standards/Approvals | UL1950, RoHS, UL |
| Minimum Input Voltage | 4.75V |
| Number of Pins | 8 |
| Output Voltage 1 | 200, 2000V |
| Output Current 1 | 5mA |
Key Features
- Operates with an input voltage range from 4.75 V to 15.5 V DC.
- Delivers an output voltage of 200 V and a peak voltage of up to 2000 V.
- Provides a maximum output power of 1 watt with output current of 5 mA.
- Designed with miniature shielded casing for chassis mounting applications.
- Features ultra-low ripple and noise at 0.0005% peak-to-peak.
- High reliability with Mean Time Between Failures (MTBF) of 2,100,000 hours.
- Suitable for operation in temperatures ranging from -10°C to 50°C.
- Complies with UL1950 and RoHS standards ensuring safety and environmental compliance.
Product Description
XP Power CA12N high-voltage DC/DC converter is a compact, shielded chassis mount power supply designed for precise and ultra-low noise voltage conversion. It supports wide input voltage from 4.75 V to 15.5 V DC and delivers regulated high voltage outputs at 200 V nominal and up to 2000 V peak. With a 1 watt power rating and 5 mA output current, this converter suits applications requiring stable and reliable high voltage in a miniature footprint.
The miniature shielded case allows for easy chassis mounting while minimizing electromagnetic interference. The design incorporates a voltage monitor, readback capability, and potentiometer or external voltage programming for fine-tuning output levels. The device is sealed to resist immersion cleaning processes, enhancing durability.
Operating temperature range is from -10°C to 50°C, making it suitable for various industrial, laboratory, and scientific environments. The unit has a high MTBF of 2,100,000 hours, ensuring long service life in demanding applications.
Peripheral features include very low EMI/RFI emission, short circuit and arc protection, and precision onboard references and calibration access. Compliance with UL1950 and RoHS certifies the converter meets safety and environmental standards.
Typical use cases include photomultiplier tubes, avalanche photodiodes, solid-state detectors, electrophoresis equipment, electro-optical lenses, piezo devices, and capacitor charging circuits commonly found in research, medical, and industrial instrumentation.
Operates with an input voltage range from 4.75 V to 15.5 V DC. Delivers an output voltage of 200 V and a peak voltage of up to 2000 V. Provides a maximum output power of 1 watt with output current of 5 mA. Designed with miniature shielded casing for chassis mounting applications.
Features ultra-low ripple and noise at 0.0005% peak-to-peak. High reliability with Mean Time Between Failures (MTBF) of 2,100,000 hours. Suitable for operation in temperatures ranging from -10°C to 50°C. Complies with UL1950 and RoHS standards ensuring safety and environmental compliance.
Ideal for use in photomultiplier tubes, solid-state detectors, electrophoresis, and capacitor charging. Explore more DC/DC Converters and related power supply solutions on EnvMart for industrial, laboratory, and scientific applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates with an input voltage range from 4.75 V to 15.5 V DC.
It delivers an output voltage of 200 V and a peak voltage of up to 2000 V.
This unit provides a maximum output power of 1 watt with an output current of 5 mA.
The converter has a length of 44.45 mm, a width of 27.94 mm, and a depth of 0.50 in.
It is suitable for operation in temperatures ranging from -10°C to 50°C.
It complies with UL1950 and RoHS standards, ensuring safety and environmental compliance.
It is designed for chassis mounting applications.
It features ultra-low ripple and noise at 0.0005% peak-to-peak.
The MTBF is rated at 2,100,000 hours, indicating high reliability.
This model has one output.
Typical use cases include photomultiplier tubes, solid-state detectors, and electrophoresis equipment.
The design includes sealing to resist immersion cleaning processes, enhancing its durability.
