Power Integrations AC/DC Converter 265V ac Input, 7A Output Current, 5V dc Output, 43W Power, eSIP-7C Package TOP264EG

The Power Integrations TOP264EG AC/DC Converter offers a high-efficiency power management solution designed for a wide range of industrial and electronic applications. It operates with a maximum input voltage of 265V ac and a minimum of 85V ac, providing flexibility for different power sources.

Featuring a robust output current capability of 7 amperes and output voltage fixed at 5V dc, this device delivers up to 43 watts of power. Packaged in the compact eSIP-7C through-hole mount, it is designed to simplify off-line AC-DC converter designs.

Utilizing the TOPSwitch-JX series Flyback topology, the converter integrates a high-voltage power MOSFET, switched current source, multi-mode PWM controller, oscillator, and extensive protection circuitry into a single monolithic package. The switching frequency is 132kHz, providing optimized efficiency and reduced component size.

This converter operates reliably over a broad temperature range from -40°C up to 150°C, making it suitable for demanding industrial environments. The device dimensions are compact with length 10.24mm, width 2.06mm, and height 8.25mm, facilitating space-saving designs.

Operates from 85V to 265V ac input voltage for versatile application. 7A maximum output current with 5V dc output for efficient power delivery. Switching frequency at 132kHz for optimized performance. Flyback converter topology implemented in the TOPSwitch-JX series.

Compact eSIP-7C package with 6-pin through-hole mount.

This AC/DC Converter is widely utilized in industrial power supply applications, electronics manufacturing, and embedded system designs requiring reliable power conversion. The integrated protection features and energy-efficient design make it ideal for low standby power designs.
