TDK VLS-EX 5045 Shielded Wirewound Surface Mount Inductor with Ferrite Core 2.2 μH ±30 % 4.7 A Idc VLS5045EX-2R2N
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | TDK |
| Height | 4.5mm |
| Length | 5mm |
| Model | VLS5045EX-2R2N |
| Depth | 5mm |
| Series | VLS-EX |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 2.2μH |
| Standards/Approvals | RoHS |
| Package/Case | 5045 |
| Maximum DC Current | 4.7A |
| Pin Count | 2 |
| Maximum DC Resistance | 220mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- Magnetically shielded for reduced electromagnetic interference.
- Compact 5045 package size with dimensions 5mm × 4.5mm × 5mm.
- Wirewound construction using ferrite core enhances magnetic characteristics.
- Operates reliably across a temperature range from -40°C to 105°C.
- Maximum DC resistance of 220 milliohms ensures efficient current flow.
- Surface mount termination style suitable for high-density circuit boards.
- Compliant with RoHS standards and moulded for durability.
- Pin count of 2 compatible with standard SMT designs.
Product Description
TDK presents the VLS5045EX-2R2N, a shielded wirewound surface mount inductor featuring a ferrite core designed for power circuit applications. This inductor offers an inductance of 2.2 μH with a tolerance of ±30%, supporting a maximum DC current of 4.7 A, making it suitable for demanding industrial and electronic uses.
The component’s 5045 package dimensions (5mm length, 4.5mm height, 5mm depth) and magnetic shielding reduce electromagnetic interference, enhancing circuit reliability. Its wirewound construction combined with ferrite core technology optimizes magnetic performance, while a maximum DC resistance of 220 milliohms ensures efficient electrical conduction.
The inductor is designed for surface mount termination, enabling high-density PCB layouts critical in modern electronics manufacturing. Operating temperature ranges from -40°C to 105°C, ensuring stable performance in diverse environmental conditions typical of industrial and commercial electronics.
The product complies with RoHS standards and features a moulded design for mechanical robustness. With a 2-pin configuration, the VLS5045EX-2R2N is versatile for integration in applications such as televisions, game consoles, set-top boxes, and audiovisual equipment.
Magnetically shielded for EMI reduction. Compact 5045 size for space-efficient board design. Wirewound ferrite core construction for high performance. Wide operating temperature: -40°C to 105°C. Low DC resistance of 220mΩ for power efficiency.
Surface mount style for automated assembly. RoHS compliant ensuring environmental safety. Moulded for durability and mechanical stability. Two pins for standard SMT connections. Applications include TVs, game devices, STBs, and AV equipment.
This TDK inductor is ideal for electronic manufacturers and engineers seeking reliable, high-current inductors with low footprint and robust shielding for sensitive circuits. Explore the full range of Surface Mount Inductors for diverse industrial and electronics applications with EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 2.2 μH with a tolerance of ±30%.
It supports a maximum DC current of 4.7 A, making it suitable for various power circuit applications.
The dimensions of the 5045 package are 5mm in length, 4.5mm in height, and 5mm in depth.
The maximum DC resistance is 220 milliohms, ensuring efficient current flow.
It operates reliably across a temperature range from -40°C to 105°C.
It features a wirewound construction using a ferrite core, which enhances its magnetic characteristics.
The inductor uses a surface mount termination style, suitable for high-density circuit boards.
Yes, it is compliant with RoHS standards, ensuring environmental safety.
It has a pin count of 2, compatible with standard SMT designs.
This inductor is suitable for applications such as televisions, game consoles, set-top boxes, and audiovisual equipment.
The country of origin for this model is Korea.
It belongs to the VLS-EX series of inductors.
