XP Power 5V, -5V Dual Output DC/DC Converter 200mA, 2W Through Hole DIP Package JCA0224D01

XP Power JCA0224D01 DC/DC Converter is a high-performance, dual output isolated voltage converter designed for demanding electronic systems. It delivers regulated 5V and -5V outputs at 200mA with a maximum output power of 2 watts. Packaged in a compact 25.4mm length by 20.3mm width by 10mm depth DIP metal case, it supports through-hole mounting with a 24-pin configuration, facilitating straightforward PCB assembly.

This converter operates efficiently over a wide input voltage range of 18V to 36V DC, making it suitable for various power supply rails and battery-powered systems. With an input ratio of 2:1, it withstands input voltage fluctuations while maintaining output stability. The product's isolation voltage rating of 1.5kV DC ensures safety and noise suppression critical in industrial and medical equipment.

Designed for reliability and longevity, the unit features an impressive MTBF of 2,000,000 hours and performs across an extended temperature range from -40°C to +100°C, tolerating extreme environmental conditions common in industrial and telecommunications settings. The converter boasts an efficiency of 76%, minimizing power losses and thermal management concerns.

Though lacking specific certifications listed, the JCA0224D01 is UL and TUV approved, ensuring compliance with international safety standards. It is manufactured in Taiwan, Province Of China, supporting global supply chain reliability.

This DC/DC converter is ideal for use in industrial controls, instrumentation, telecommunications power supplies, and medical devices where compact size, dual isolated voltages, and reliable operation are paramount.

Provides isolated dual outputs of 5V and -5V for versatile applications. Operates over a wide input voltage range from 18V to 36V DC. Compact 25.4mm x 20.3mm x 10mm DIP metal package suitable for through-hole mounting. High reliability with a mean time between failures (MTBF) of 2,000,000 hours.

Wide operating temperature range from -40°C up to +100°C for harsh environments. Isolation voltage rating of 1.5kV DC ensures electrical safety and noise immunity. Efficiency rated at 76% for effective power conversion and reduced heat.

Industry standard 24-pin configuration allows easy PCB integration. Robust construction with UL and TUV approvals enhances quality assurance. Ideal for industrial, medical, and telecommunications power conversion applications.

Explore the wide range of DC/DC Converters at EnvMart to find fully featured power conversion solutions suitable for all your industrial, medical, and telecommunications needs. XP Power products are known for quality and reliability in power management components.
