Wurth Elektronik WR-PHD Series Bottom Entry Through Hole PCB Socket 5-Contact 1 Row 2.54 mm Pitch 61300515721
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500V |
| Brand | Wurth Elektronik |
| Orientation | Bottom Entry |
| Current | 3A |
| Mount Type | Through Hole |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Durability | 25mating cycles |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | PCB Socket |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Connector System | Board-to-Board |
Key Features
- Designed for through hole mounting with bottom entry orientation.
- Supports currents up to 3A and voltage rating of 500V.
- Contact material is copper alloy with gold plating for durability and conductivity.
- Operating temperature range from -40°C to 105°C suitable for various environments.
- Durability rated for 25 mating cycles ensuring reliable repeated use.
- Made from PA9T insulator material with UL94 V-0 flammability rating.
- Certified RoHS compliant contributing to environmental safety.
- Connector system is board-to-board, ensuring secure PCB connections.
Product Description
Wurth Elektronik 61300515721 is a bottom entry through hole PCB socket from the WR-PHD series providing reliable board-to-board connections with 5 contacts arranged in a single row at a 2.54 mm pitch. It is engineered with copper alloy contacts plated in gold for excellent conductivity and corrosion resistance, housed in a PA9T insulator material that meets UL94 V-0 flammability standards. Designed to operate in demanding environments, it has an operating temperature range from -40°C up to 105°C and supports a current rating of 3A with a voltage rating of 500V.
This PCB socket features through hole mounting and bottom entry orientation, facilitating robust mechanical and electrical connections on printed circuit boards. Its construction and materials ensure a durability of 25 mating cycles, suitable for industrial, electronics manufacturing, laboratory, and commercial applications where secure and long-lasting PCB connections are required. The socket is RoHS compliant and UL approved under E323964, guaranteeing compliance with international safety and environmental standards.
This Wurth Elektronik WR-PHD series PCB socket is ideally suited for electronic component assemblies that require reliable bottom entry connectivity and high electrical performance. It is manufactured in Taiwan and designed to meet strict quality levels for professional and industrial electronic equipment assembly.
Designed for through hole mounting with bottom entry orientation. Supports currents up to 3A and voltage rating of 500V. Contact material is copper alloy with gold plating for durability and conductivity. Operating temperature range from -40°C to 105°C suitable for various environments.
Durability rated for 25 mating cycles ensuring reliable repeated use. Made from PA9T insulator material with UL94 V-0 flammability rating. Certified RoHS compliant contributing to environmental safety. Connector system is board-to-board, ensuring secure PCB connections.
Explore the Wurth Elektronik WR-PHD series and related PCB Socket solutions at EnvMart for professional electronics manufacturing and repair.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a voltage rating of 500V, making it suitable for high-voltage applications.
This model supports a current rating of up to 3A, allowing it to handle moderate electrical loads.
The operating temperature range is from -40°C to 105°C, suitable for various environmental conditions.
It features 5 contacts arranged in a single row, designed for reliable board-to-board connections.
The contact pitch size is 2.54 mm, which is standard for many PCB applications.
The contacts are made from copper alloy with gold plating, and the insulator material is PA9T, which meets UL94 V-0 flammability standards.
This socket is rated for 25 mating cycles, ensuring reliable repeated use in applications.
It supports through hole mounting with a bottom entry orientation, facilitating secure installation on PCBs.
Yes, it is certified RoHS compliant, contributing to environmental safety standards.
It is manufactured in Taiwan, adhering to strict quality levels for professional use.
This socket uses solder termination, which is standard for PCB connections.
It utilizes a board-to-board connector system, ensuring secure connections between printed circuit boards.
