Wurth Elektronik WR-PHD Series Straight Surface PCB Socket, 6-Contact, 1 Row, 2.54 mm Pitch 61000611921
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Surface |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Durability | 25mating cycles |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Connector System | Board-to-Board |
Key Features
- This PCB socket supports a current capacity of 3 Amps.
- The socket is designed for surface mounting with a straight orientation for board-to-board connections.
- It features copper alloy contact material with gold plating for excellent conductivity.
- The operating voltage rating is 500V, suitable for various electronic applications.
- With an operating temperature range from -40°C to 125°C, it is reliable under harsh conditions.
- The insulator is made of PA9T with a UL94 V-0 flammability rating enhancing safety.
- Durability supports up to 25 mating cycles ensuring long-term usage.
- This model is lead-free and RoHS compliant, meeting environmental standards.
Product Description
Wurth Elektronik 61000611921 PCB Socket, part of the WR-PHD Series, is a straight surface mount socket featuring 6 contacts arranged in a single row with 2.54 mm pitch. This component is designed for board-to-board connections, providing secure and reliable electronic interfacing suitable for industrial and commercial applications.
The socket supports a current rating of 3A and a voltage rating of 500V, making it ideal for various electronic machines and equipment that require robust connectivity. It features copper alloy contacts plated with gold to ensure excellent electrical performance and corrosion resistance.
Operating safely within -40°C to 125°C, it withstands a broad temperature range suitable for harsh and demanding environments. The insulator is manufactured from PA9T material, certified with a UL94 V-0 flammability rating, enhancing safety in electrical assemblies.
This PCB socket is designed for surface mount technology (SMT) with a straight orientation, simplifying mounting on printed circuit boards in electronic industrial applications such as power and connector systems.
The product is lead-free and RoHS compliant, supporting environmentally responsible manufacturing and usage standards. Its durability is rated for 25 mating cycles, offering reliable performance and longevity in repeated connections.
This PCB socket supports a current capacity of 3 Amps. Designed for surface mount installation with straight orientation. Gold plated copper alloy contacts ensure reliable conductivity. Operational voltage rating of 500V suitable for industrial uses.
Wide temperature tolerance from -40°C to 125°C for applicability in various environments. Durability rated for 25 mating cycles for long-term reliability. Lead-free and RoHS compliant, promoting environmental sustainability.
This product is ideal for electronics manufacturing, industrial control systems, power electronics assemblies, and other applications requiring reliable, durable PCB connectivity. Explore more PCB Sockets from Wurth Elektronik in EnvMart for comprehensive solutions in electronic components and connectors.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket supports a current capacity of 3 Amps.
The operating voltage rating for this model is 500V, making it suitable for various electronic applications.
The contacts of this PCB socket are arranged with a pitch size of 2.54 mm.
This socket features 6 contacts arranged in a single row.
The contacts are made of copper alloy and are plated with gold to ensure excellent conductivity.
It operates safely within a temperature range from -40°C to 125°C.
This model is rated for up to 25 mating cycles, ensuring reliable performance during repeated connections.
This socket is designed for surface mounting with a straight orientation.
The insulator is made of PA9T material and has a UL94 V-0 flammability rating, enhancing safety in electrical assemblies.
Yes, this model is lead-free and RoHS compliant, promoting environmentally responsible manufacturing and usage standards.
This model is suitable for electronics manufacturing, industrial control systems, and power electronics assemblies that require reliable PCB connectivity.
The country of origin for this PCB socket is Taiwan.
