STMicroelectronics 1-Element Uni-Directional TVS Diode 1.5 kW Peak Pulse Power 2-Pin DO-201 1.5KE82A

STMicroelectronics 1.5KE82A is a 1-element, uni-directional Transient Voltage Suppression (TVS) diode designed for protecting sensitive electronic devices from voltage spikes. It features a peak pulse power dissipation of 1.5 kW and a robust DO-201 through-hole package with 2 pins. Its minimum breakdown voltage is 77.9 V, with a maximum reverse stand-off voltage of 70 V, making it suitable for steady voltage protection in power electronics and industrial circuits.

This TVS diode has a clamping voltage of 146 V and can withstand peak pulse currents up to 69 A, providing reliable suppression of transient overvoltages and preventing damage to downstream components. It supports extreme operating temperatures ranging from -65°C to +175°C, allowing stable operation in harsh environments.

The component has a minimal maximum reverse leakage current of 1 µA, which helps maintain energy efficiency. Its compact axial dimensions of 9.5 mm length by 5.3 mm diameter allow for easy integration into printed circuit boards requiring through-hole mounting. The diode is designed as a single element for uni-directional transient voltage protection.

This product is suitable for use in various applications such as industrial electronics, power supply protection, consumer electronics, and other areas where transient voltage surges need to be suppressed effectively.

Single diode configuration designed for uni-directional protection. Minimum breakdown voltage of 77.9 V ensures reliable surge suppression. Maximum reverse stand-off voltage of 70 V suitable for through-hole mounting. Clamping voltage rated at 146 V to protect sensitive circuits.

Operates within a temperature range from -65°C to 175°C for robust performance. Test current of 1 mA and peak pulse current of 69 A handling transient spikes effectively. Compact dimensions with 9.5 mm length and 5.3 mm diameter.

Low maximum reverse leakage current of 1 µA minimizes power loss. Non-automotive standard component ideal for industrial and electronic applications. Durable DO-201 package suitable for various power protection requirements.
