Wurth Elektronik 3587 Series Pluggable Terminal Block 2-Contact 5.08 mm Pitch 1 Row 7A 300V AC 691358710002

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 3587 Series Pluggable Terminal Block 2-Contact 5.08 mm Pitch 1 Row 7A 300V AC 691358710002

Name: Wurth Elektronik 3587 Series Pluggable Terminal Block 2-Contact 5.08 mm Pitch 1 Row 7A 300V AC 691358710002
Brand: Wurth Elektronik
SKU: 189092



Category Pluggable Terminal Blocks Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	300V ac
Brand	Wurth Elektronik
Colour	Orange, Green
Orientation	Horizontal
Current	7A
Length	10.16mm
Depth	29.5mm
Width	14mm
Housing Material	Polyamide 66
Series	3587
Number of Rows	1
Pitch	5.08mm
Standards/Approvals	RoHS
Number of Contacts	2
Connector Gender	Male
Minimum Wire Size mm²	0.3mm²
Maximum Wire Size mm²	0.8mm²
Minimum Wire Size AWG	22AWG
Maximum Wire Size AWG	18AWG
Wire Connection Method	Screw

Key Features

This terminal block features a horizontal orientation for easy wiring and installation.
It supports wire sizes ranging from 22 to 18 AWG (0.3 to 0.8 mm²).
The housing is made of durable Polyamide 66 with green and orange UL94-V0 flame-retardant material.
Connections are secured via screw wire connection method providing reliable contact.
The 3587 series includes stamped tin-plated copper alloy IDC contacts for improved conductivity.
The compact dimensions are 29.5 mm depth, 14 mm width and 10.16 mm length.
This product complies with RoHS standards ensuring environmental safety and chemical compliance.
Ideal for industrial applications requiring modular and pluggable terminal block solutions.

Product Description

Wurth Elektronik 691358710002 Pluggable Terminal Block from the 3587 Series is a high-quality electrical connector engineered to facilitate safe and reliable connections in electronic and industrial control systems. Supporting a current rating of 7A and voltage up to 300V AC, it is designed for robust performance in demanding environments.

This pluggable terminal block features a 2-contact, 1-row configuration with a 5.08 mm pitch, allowing for space-efficient wiring layouts. The connector housing is crafted from flame-retardant Polyamide 66 (UL94-V0 rated), available in green and orange colors, enhancing durability and safety.

The electrical contacts consist of stamped, tin-plated copper alloy IDC contacts, providing excellent conductor retention and electrical conductivity. It accommodates horizontal wire entry with wire sizes from 22 to 18 AWG (0.3 to 0.8 mm²), secured by a reliable screw connection method.

With dimensions measuring 29.5 mm in depth, 14 mm in width, and 10.16 mm in length, this compact connector is tailored for use in various applications - ranging from industrial automation, machinery wiring, electronic component assemblies, to building electrical installations.

The product adheres to RoHS compliance, ensuring reduced environmental impact and health safety. Manufactured to precise standards, it enables modular assembly and easy maintenance in electrical setups.

This terminal block features a horizontal orientation for easy wiring and installation. Supports wire sizes ranging from 22 to 18 AWG (0.3 to 0.8 mm²). Housing consists of durable, flame-retardant Polyamide 66 material. Reliable screw wire connection method ensures secure contact.

Stampled tin-plated copper alloy contacts for excellent conductivity. Compact dimensions suitable for space-saving electrical designs. Complies with RoHS environmental and safety standards. Suitable for industrial and electronic applications requiring Pluggable Terminal Blocks.

Explore EnvMart for a wide range of Wurth Elektronik components and industrial electrical connectors ensuring quality and performance in your projects.
