HARWIN M80 Series Straight Through Hole PCB Socket, 12-Contact, 2 Row, 2 mm Pitch, Board-to-Board, 120V, 12A M80-8501242

HARWIN M80-8501242 is a precision engineered straight through hole PCB socket from the M80 Series, designed for reliable board-to-board connections in demanding applications. This 12-contact, 2-row socket features 2 mm pitch and is constructed with a durable nylon housing to withstand harsh industrial environments.

The contact material is a high-reliability beryllium copper alloy, featuring gold plating that ensures excellent conductivity and corrosion resistance. Its four-finger clip contact design guarantees consistent electrical connection even under severe shock, vibration, and acceleration conditions.

This socket has a maximum operating voltage of 120V and current rating of 12A, suitable for robust electronics assemblies. The device supports a wide temperature operating range from -55°C to 125°C, making it ideal for industrial, laboratory, manufacturing, and commercial electronics applications.

Mounting is via through hole technology with a vertical PC tail orientation for secure soldering and stability. The polarized mouldings enhance correct mate alignment and system integrity while supporting multiple mating cycles without degradation.

The M80 series sockets are compliant with standards including BS9525-F0033, MIL C 55302, and CEC 75101-008, ensuring suitability for critical and high-reliability products. Manufactured in the United Kingdom, this component delivers assured quality and durability.

The socket features a nylon housing for enhanced durability. Beryllium copper alloy contacts provide excellent conductivity and mechanical resilience. Contacts are gold plated for superior corrosion resistance and signal integrity.

Designed for through hole mount with vertical PC tail orientation. Operates reliably across a temperature range from -55°C to 125°C. The connector system is polarized and supports high mating cycle durability. Meets performance standards including BS9525-F0033, MIL C 55302, and CEC 75101-008.

Manufactured in the United Kingdom ensuring high quality standards.

This PCB socket is ideal for use in electronic component assemblies requiring reliable electrical connections with high robustness, including industrial machinery, electronic instrumentation, control systems, and commercial electronics.
