Texas Instruments Operational Amplifier 4-Channel Surface Mount SOIC 14-Pin, 100 MHz Gain Bandwidth, 5.5V OPA4354AID

Texas Instruments OPA4354AID is a high-performance operational amplifier featuring four independent channels, designed for demanding industrial, video processing, and precision applications. This 14-pin SOIC surface mount device delivers a 100 MHz gain bandwidth product, making it well-suited for wide bandwidth and fast signal processing tasks. Its operating voltage range spans from 3 V up to a maximum of 5.5 V, providing flexibility in various circuit designs.

The amplifier boasts an exceptionally high slew rate of 150 V/μs, enabling rapid voltage changes with minimal distortion. Its low input bias current of ±50 pA and minimal input offset voltage of ±10 mV ensure accurate amplification and signal fidelity. The OPA4354AID also supports unity-gain stability and offers a wide unity-gain bandwidth of 250 MHz, delivering excellent video performance with differential gain of just 0.02% and differential phase of 0.09°.

Thermal management is incorporated with a thermal shutdown feature to protect the device from overheating. The compact SOIC package has dimensions of 8.65 mm in length, 3.91 mm in width, and 1.58 mm in height, optimized for space-saving printed circuit board layouts. Operating temperature range of -40°C to 125°C makes it suitable for rugged industrial and automotive applications.

This amplifier is compliant with RoHS directives and meets the AEC-Q100 automotive standard, ensuring environmentally friendly and high-quality performance. The device’s low noise figure of 6.5 nV/√Hz and high output current capability greater than 100 mA enable it to drive heavy loads and maintain signal integrity.

Operates between 3 V and 5.5 V supply voltage. Four independent amplifier channels for multi-signal processing. Slew rate of 150 V/μs for high-speed operation. Low input bias and offset currents for precision applications.

Thermal shutdown for device protection. Compact SOIC 14-pin surface mount package. Compliant with RoHS and automotive AEC-Q100 standard. Low noise and high output current capacity. Wide operating temperature range from -40°C to 125°C.

This Texas Instruments OPA4354 series operational amplifier is ideal for integration into industrial machinery, video electronics, instrumentation, and automotive circuits requiring precise, high-speed amplification. Explore more products in the Semiconductor and Operational Amplifier categories at EnvMart for advanced electronic component solutions.
