Festo Pneumatic Cylinder 16 mm Bore, 100 mm Stroke, Air Cushion, Direct Mount, Stainless Steel Piston Rod, DSNU-16-100-PPV-A

Festo DSNU-16-100-PPV-A Pneumatic Cylinder is a high-quality pneumatic piston rod cylinder designed for precise linear motion in pneumatic systems. Featuring a 16 mm bore diameter and a 100 mm stroke length, this double-acting cylinder offers reliable and efficient performance across various industrial applications.

The cylinder housing is made of a robust wrought aluminium alloy cover that provides excellent protection against wear and impact, ensuring long service life. Its stainless steel piston rod is male-threaded with metric threading standard for secure and adaptable mounting options. The DSNU series features adjustable pneumatic cushioning at both ends, which allows for smooth deceleration and energy absorption, reducing mechanical shock and wear.

Operating within a temperature range of -20°C to +80°C, this cylinder is suitable for use in challenging environments including medical devices, packaging machinery, and oil and gas plants. It supports a wide operating pressure range from 1 to 10 bar, providing versatile application potential from light-duty to medium-heavy-duty operations.

Conformity with ISO 6432 and Germanischer Lloyd standards assures quality and dimensional compatibility, while ATEX certification makes it safe for environments with explosive gas atmospheres. Its compact overall length of 211 mm enables installation in space-constrained setups. The direct mount and steel piston rod ensure durability and stability during operation.

Constructed with a lightweight wrought aluminium alloy cover for durability and impact resistance. Stainless steel piston rod with male metric thread offers robust mounting options. Adjustable pneumatic cushioning for smooth cushioning and energy absorption at cylinder ends.

Wide operating temperature range from -20°C to 80°C for reliability in harsh environments. Supports 1 to 10 bar pressure for flexible application in diverse industrial tasks. Complies with ISO 6432, Germanischer Lloyd standards and ATEX gas certification.

Double-acting pneumatic cylinder for precision motion control. Suitable for industries including medical, process and packaging, and oil & gas plants. Compact 211 mm total length with 100 mm stroke length.

Festo pneumatic cylinders like the DSNU-16-100-PPV-A are essential components in automated industrial machinery, offering precise and reliable motion control in pneumatic systems. Browse EnvMart’s range of Pneumatic Cylinders for all your pneumatic actuator requirements.
