Nexperia 8-Channel Buffer & Line Driver, 3 State, Non-Inverting, 20-Pin SOIC Operating Voltage 4.5 to 5.5V 74HCT244D,652
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 2.65mm |
| Length | 13mm |
| Model | 74HCT244D,652 |
| Width | 7.6mm |
| Mount Type | Surface |
| Compatibility | Input TTL, Output CMOS |
| Output type | 3 State |
| Series | 74HCT244 |
| Input Type | Single Ended |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Polarity | Non-Inverting |
| IC Type | Buffer & Line Driver |
| Number Of Channels | 8 |
| Pin Count | 20 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | 74HCT |
| Logic Function | Buffer & Line Driver |
| Minimum Supply Voltage | 4.5V |
| Maximum High Level Output Current | -6mA |
| Maximum Propagation Delay Time @ CL | 33ns |
| Supply Current | 160μA |
| Maximum Low Level Output Current | 6mA |
| NXP 74HCT244N,652 Octal-Channel Buffer & Line Driver, 3-State, 20-Pin PDIPBrand | NXP |
Key Features
- This device operates at a voltage range of 4.5 to 5.5 volts.
- It features 8 channels with single-ended input and 3-state output capabilities.
- The buffer & line driver functions with non-inverting polarity for signal integrity.
- Compact surface-mount SOIC package with 20 pins enables easy PCB integration.
- Operating temperature range extends from -40°C to 125°C for reliability in varied environments.
- High-speed CMOS design allows maximum propagation delay time of 33 nanoseconds at CL.
- Supply current is low at approximately 160 microamperes, ensuring energy efficiency.
- Maximum high-level output current is -6 mA, and low-level output current is 6 mA.
Product Description
Nexperia 74HCT244D,652 8-Channel Buffer & Line Driver, model 74HCT244D,652, is a non-inverting, 3-state buffer designed for reliable signal buffering and driving in electronic circuits. This device, supplied in a 20-pin SOIC surface-mount package, operates over a voltage range of 4.5 to 5.5 volts. It features eight independent channels with single-ended inputs and 3-state outputs, making it suitable for bus interface and buffer applications in industrial control systems, communications equipment, and embedded electronics.
The high-speed CMOS design ensures a maximum propagation delay time of 33 nanoseconds at specified load capacitance, enabling fast signal processing with minimal distortion. Operating temperature ranges from -40°C to 125°C allow deployment in demanding environments including automotive, industrial, and HVAC control systems.
With a low supply current of 160 microamperes, this buffer reduces power consumption while maintaining consistent output drive capability of ±6 mA. Its compatibility with TTL inputs and CMOS outputs allows easy integration with a broad range of digital logic devices.
The compact SOIC package dimensions (length 13 mm, width 7.6 mm, height 2.65 mm) support high-density PCB layouts and surface-mount assembly efficiency. This device operates at a voltage range of 4.5 to 5.5 volts. Features 8 channels with non-inverting 3-state outputs for flexible signal control.
Compact 20-pin SOIC surface-mount package for efficient PCB integration. High-speed CMOS logic for propagation delay time of up to 33 ns. Wide operating temperature range from -40°C to 125°C. Low supply current of approximately 160 μA reduces energy consumption.
Compatible with TTL input and CMOS output logic levels. Output current capability of ±6 mA supports various load requirements. Suitable for industrial, automotive, and electronic interface applications. Reliable signal buffering and driving for line interface IC needs.
This buffer and line driver is ideal for applications in industrial automation, automotive electronics, embedded control systems, and communications infrastructure where precise signal handling is critical. Explore more semiconductor solutions and buffer ICs on EnvMart for your electronic design needs.
Explore more products in our Line Interface ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates within a voltage range of 4.5 to 5.5 volts.
This model supports 8 independent channels with single-ended inputs.
The maximum propagation delay time is 33 nanoseconds at specified load capacitance.
The supply current is approximately 160 microamperes, which helps reduce power consumption.
The dimensions of the package are 13 mm in length, 7.6 mm in width, and 2.65 mm in height.
It is compatible with TTL input and CMOS output logic levels.
The operating temperature range extends from -40°C to 125°C.
It has a maximum high-level output current of -6 mA and a low-level output current of 6 mA.
This device uses a surface mount type for easy PCB integration.
It is suitable for applications in industrial automation, automotive electronics, embedded control systems, and communications infrastructure.
The outputs are non-inverting, which helps maintain signal integrity.
This device is classified as a Buffer & Line Driver.
