Hirose DF11 Series Straight Surface PCB Header, 20 Contact(s), 2 mm Pitch, 2 Row, Shrouded

Hirose DF11CZ-20DP-2V(27) is a Straight Surface PCB Header from the DF11 Series featuring 20 contacts arranged in 2 rows with a 2 mm pitch. This shrouded connector utilizes a polyamide housing material and copper alloy contacts plated with tin to ensure durability and reliable electrical performance.

The design includes a compact footprint with a depth of less than 5 mm, allowing double-row contacts within the space of a single row, maximizing PCB real estate efficiency. It features guide ribs and a locking mechanism to prevent incorrect insertion and ensure secure mating connections. Metal fittings on the surface mount versions provide enhanced retention on the PCB and help prevent solder peeling.

This PCB header supports a voltage rating of 250 V and current of 2 A, with an operating temperature range of -30°C to 85°C. Termination is via solder, and the connector is oriented straight, making it suitable for precise and reliable surface mounting.

The DF11 Series connectors are ideal for use in electronic applications demanding multiple signals within a limited space, including digital cameras, LCD displays, digital video recorders, car navigation systems, access control units, and measurement devices.

These connectors support both board-to-board and wire-to-board systems, offering design flexibility for various industrial and consumer electronics applications. The robust shrouded housing protects contact integrity, making this connector suitable for demanding electrical and mechanical environments.

Compact, space-saving double row design with 2 mm pitch for precise PCB applications. Shrouded housing with polyamide material ensuring mechanical protection. Operates with a voltage rating of 250 V and a current rating of 2 A.

Surface mount type with solder termination for reliable PCB attachment. Copper alloy contacts plated with tin for enhanced conductivity and corrosion resistance. Operating temperature range from -30°C to 85°C suitable for various environments.

Includes locking mechanism and guide ribs to prevent mismating and secure connections. Suitable for both board-to-board and wire-to-board connector systems. Robust design including metal fittings on SMT versions for strong PCB retention and solder integrity.

Ideal for electronics such as digital cameras, LCD displays, and measurement devices. Explore more electronic components and PCB Connectors at EnvMart for your industrial, commercial, and consumer device needs.
