TE Connectivity AMP-LATCH Series Straight Through Hole PCB Header, 40 Contacts, 2.54 mm Pitch, 2 Row, Shrouded 5103308-8

TE Connectivity 5103308-8 PCB Header belongs to the AMP-LATCH Series, featuring a straight through hole mounting design with a pitch of 2.54 mm and 40 contacts arranged in 2 rows. It is shrouded to provide reliable mating and protection from environmental factors. The housing is made from thermoplastic material, combining electrical insulation and mechanical strength.

The connector is designed for wire-to-board connections, widely used in industrial electronics, communication devices, and equipment assemblies. Each contact is manufactured from a copper alloy with gold plating to enhance conductivity and resist oxidation, supporting a current capacity of 1A and a voltage rating of 250V. The termination type is solder, with a male contact gender and a tail pin length of 3.05 mm, facilitating robust and durable PCB mounting.

The product is rated for operation within a temperature range from -55°C to 105°C, ensuring stable performance under various environmental conditions. Though there are no explicit certifications, the AMP-LATCH series is known for providing cost-effective and time-saving interconnection solutions particularly suitable for industrial, laboratory, automotive, and electronic manufacturing applications.

Designed to fit 2.54 mm pitch grids, this PCB header enables compatibility with standard ribbon cables and connectors. The shrouded design aids in preventing incorrect orientation and increases the reliability of connections by protecting the contacts against damage. This product is a valuable component for circuit board assemblies demanding durable and consistent wire-to-board interface solutions.

The 2.54 mm pitch complies with standard PCB mounting grids. It supports a current rating of 1A for modest electrical loads. Constructed with thermoplastic housing for durability and insulation. The contact material is copper alloy with gold plating to ensure solid conductivity and corrosion resistance.

Designed for through-hole solder mounting with male contact gender and 3.05 mm tail pin length. Operates reliably in temperatures ranging from -55°C to 105°C. The connector system is wire-to-board, suitable for various electronic applications.

Shrouded construction adds protection and prevents misalignment during mating. Supports voltage up to 250V, ensuring safe operation in low voltage circuits. This connector meets no formal certifications but offers a robust mechanical and electrical interface.
