KEMET R60 Film Capacitor Through Hole Mount 10 nF ±5 % 630 V dc 220 V ac R60PF2100AA30J
Specifications
| Country of Origin | India |
|---|---|
| Capacitance Range | 0.001 μF - 150.0 μF |
| Voltage Range | 50 to 1000 V dc |
| Brand | KEMET |
| Height | 9mm |
| Length | 13mm |
| Model | R60PF2100AA30J |
| Packaging | Bag |
| Width | 4mm |
| Mount Type | Through Hole |
| Series | R60 |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±5 % |
| Capacitance | 10nF |
| Minimum Operating Temperature | -55°C |
| Climatic category | 55/105/56 |
| Lead Length | 25mm |
| Standards/Approvals | IEC 60286-2, UL 94V-0, RoHS |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 220V ac |
| Rated DC Voltage | 630V dc |
| Lead Pitch | 10mm |
| Lead Diameter | 0.6mm |
| Automotive Standard | AEC-Q200 |
| Capacitance tolerance | ±5%, ±10%, ±20% |
| Lead Spacing | 10.0 to 37.5 mm |
Key Features
- Designed for blocking, bypassing, coupling, oscillator, and timing applications.
- Constructed with plastic case meeting UL 94V-0 fire resistance standard.
- Lead pitch of 10 mm and lead length of 25 mm for secure installation.
- Rated for operating temperatures from -55°C to +105°C ensuring reliability under harsh conditions.
- Compliance with IEC 60286-2, RoHS, and automotive standard AEC-Q200 for quality assurance.
- Package supplied in bags ready for insertion into manufacturing processes.
- Pin diameter of 0.6 mm and dimensions of 13 mm length, 4 mm width, and 9 mm height.
Product Description
KEMET R60PF2100AA30J Film Capacitor is a through hole mount passive electronic component with a capacitance of 10 nF and capacitance tolerance of ±5 %. It is rated for 630 V dc and 220 V ac operating voltages, making it suitable for various electronic circuit applications requiring stable capacitance.
This capacitor series is encapsulated in a plastic case that meets UL 94V-0 flammability requirements and is designed with tinned radial leads for secure mounting on printed circuit boards. Its lead pitch of 10 mm and lead length of 25 mm facilitate reliable mechanical and electrical connections.
Its wide operating temperature range of -55°C to +105°C ensures dependable performance in industrial, automotive, and other demanding environments. The capacitor complies with multiple industry standards including IEC 60286-2, UL 94V-0, RoHS directives, and the automotive-grade AEC-Q200 standard, confirming its suitability for automotive electronics.
Typical applications include blocking, coupling, decoupling, bypassing, oscillation, timing circuits, and interference suppression in low voltage electronic assemblies. The product is packaged in bags, prepared for insertion and assembly in manufacturing processes, enhancing production efficiency.
Designed for blocking, bypassing, coupling, oscillator, and timing applications. Constructed with plastic case meeting UL 94V-0 fire resistance standard. Lead pitch of 10 mm and lead length of 25 mm for secure installation.
Rated for operating temperatures from -55°C to +105°C ensuring reliability under harsh conditions. Compliance with IEC 60286-2, RoHS, and automotive standard AEC-Q200 for quality assurance. Package supplied in bags ready for insertion into manufacturing processes.
Pin diameter of 0.6 mm and dimensions of 13 mm length, 4 mm width, and 9 mm height.
This capacitor is ideal for use in electronic, industrial automation, automotive, and manufacturing processes where reliable passive components enhance circuit stability. Available through EnvMart's electronics components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this model is 10 nF with a tolerance of ±5%.
It is rated for 630 V dc and 220 V ac, making it suitable for various electronic applications.
The dimensions are 13 mm in length, 4 mm in width, and 9 mm in height, with a lead length of 25 mm.
The lead pitch is 10 mm with a lead diameter of 0.6 mm, facilitating secure installation.
It complies with IEC 60286-2, UL 94V-0, RoHS directives, and the automotive standard AEC-Q200.
Typical applications include blocking, coupling, decoupling, bypassing, oscillation, timing circuits, and interference suppression.
It is supplied in bags, ready for insertion into manufacturing processes, enhancing production efficiency.
The climatic category is 55/105/56, indicating its performance in various environmental conditions.
This model is encapsulated in a plastic case that meets UL 94V-0 flammability requirements.
It is designed for use in low voltage electronic assemblies, making it suitable for industrial, automotive, and other demanding environments.
