Nexperia Zener Diode 1.47 V Single 500 mW 5% Surface Mount 2-Pin SOD-80 BZV55-C47,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Zener Diode 1.47 V Single 500 mW 5% Surface Mount 2-Pin SOD-80 BZV55-C47,115

Name: Nexperia Zener Diode 1.47 V Single 500 mW 5% Surface Mount 2-Pin SOD-80 BZV55-C47,115
Brand: Nexperia
SKU: 180606
Price: 0.05 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.6mm
Length	3.7mm
Model	BZV55-C47,115
Mount Type	Surface
Series	BZV55
Maximum Operating Temperature	200°C
Package Type	SOD-80
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	2mA
Maximum Reverse Leakage Current	50nA
Nominal Zener Voltage Vz	47V
Zener Type	Voltage Regulator
Maximum Zener Impedance	170Ω
Typical Voltage Temperature Coefficient	42.9mV/°C

Key Features

This diode is configured for voltage regulation and utilizes a 2-pin surface mount SOD-80 package.
It features a typical voltage temperature coefficient of 42.9 mV/°C and a voltage tolerance of ±5% for reliable voltage stabilization.
Designed for operation at temperatures ranging from -65°C to 200°C ensuring robust performance in variable environments.
The device has a maximum reverse leakage current of 50 nA and Zener impedance of 170 Ω at the test current of 2 mA.
Compact dimensions with a length of 3.7 mm and height of 1.6 mm support high-density PCB applications.
Manufactured in China and suitable for use in electronic applications requiring precise voltage regulation.

Product Description

Nexperia BZV55-C47,115 Zener Diode is a high-quality surface mount voltage regulator component designed for precise voltage stabilization in electronic circuits. It has a nominal Zener voltage of 47 V and can dissipate up to 500 mW power, making it suitable for various industrial, laboratory, and electronic manufacturing applications.

This single element diode features a 2-pin SOD-80 package, which provides an efficient surface mount solution for compact circuit designs. The diode operates efficiently with a test current of 2 mA, maintaining a maximum Zener impedance of 170 Ω and a low reverse leakage current of 50 nA, ensuring minimal power loss and high reliability.

Designed to withstand a wide range of operating temperatures, from -65°C to 200°C, this diode is ideal for use in demanding environments such as automotive electronics, power supplies, and voltage reference circuits. The typical voltage temperature coefficient of 42.9 mV/°C guarantees stable performance over temperature variations.

With compact dimensions of 3.7 mm length and 1.6 mm height, the diode supports high-density printed circuit board layouts. Manufactured in China under the BZV55 series, this Nexperia component complies with industry standards for discrete semiconductors but does not carry specific certifications.

This diode is configured for single element voltage regulation. Features a 2-pin SOD-80 surface mount package for easy PCB assembly. Supports power dissipation of up to 500 mW ensuring effective voltage control. Nominal Zener voltage is 47 V with ±5% tolerance for accuracy.

Wide operating temperature range supports varied industrial applications. Low reverse leakage current and impedance optimize device efficiency.

This product is suitable for industrial, electronic component manufacturing, power supply design, and laboratory applications where precise voltage regulation is critical. EnvMart provides this Nexperia Zener Diode BZV55-C47,115 as a reliable solution for demanding electronic designs. Explore our Zener Diode category for related products and advanced components.
