Lorlin 2 Position 4PST Rotary Switch 500mA 250V AC/DC PCB Mount Solder Terminals PT6596

Lorlin PT6596 is a high-quality 2 Position 4PST rotary switch optimized for PCB mounting, rated for 500mA contact current at 250V AC/DC, and operated via solder terminals. The switch’s polyethylene terephthalate housing provides robust mechanical protection and electrical insulation suitable for various industrial and electronic applications.

With a compact design featuring dimensions of approximately 35.25mm width, 31.4mm height, and 16.65mm depth, this rotary switch includes a 6mm diameter shaft and a 30° angle of throw for precise position control. It has a 4-pole configuration, allowing complex circuit switching.

Designed for reliability, the PT6596 supports a mechanical life of 10,000 operations, and its operating temperature range from -30°C to 85°C makes it suitable for harsh environments. The switch includes break-before-make wafers and a fixed non-interchangeable drive wafer, ensuring stable switching performance.

A comprehensive spacer kit is supplied, which contains 10 spacers, 2 front insulators, 1 rear driver shaft, 1 retaining strap, 2 tie rods, and 2 push-on fixings. These allow extension with up to five additional wafers to customize the switch configuration while maintaining correct wafer pitch.

Terminal spacing is standardized at 2.54mm pitch, enabling compatibility with common PCB layouts. The PT6596 switch meets RoHS compliance, affirming its adherence to environmental and safety standards.

Ideal for use in electrical circuits requiring reliable position switching, this switch finds application in industrial controls, automation systems, HVAC, manufacturing electronics, and various laboratory equipment setups. Its precise engineering provides dependable operation in demanding technical environments.

The switch has a polyethylene terephthalate housing for durability. It offers 2 positions with a 30° angle of throw and 4 poles (4PST configuration). Designed for a mechanical life of 10,000 operations. Suitable for operating temperatures between -30°C and 85°C.

Features a 6mm diameter shaft and terminal spacing on a 2.54mm pitch. Mount type is PCB, allowing easy board integration with solder termination. The switch uses a break-before-make wafer system and comes equipped with a non-interchangeable drive wafer.

It complies with RoHS standards ensuring environmental safety. Includes a spacer kit for maintaining 6.35mm pitch between wafers, allowing configuration flexibility. Explore the comprehensive range of Rotary Switches at EnvMart for your industrial and electronic needs.
