Nexperia 1, 2.2 V Zener Diode, Single 365 mW 5 % Surface Mount DFN1006BD-2 BZX8850S-C2V2-QYL

Nexperia BZX8850S-C2V2-QYL is a high-performance 1, 2.2 V nominal Zener diode designed for voltage regulation in compact electronic circuits. Packaged in a small 2-pin DFN1006BD-2 surface mount device, it supports a maximum power dissipation of 365 mW. This component is optimized for low-current applications, with a test current of 50 μA, making it suitable for portable battery-powered devices and low-bias circuit requirements.

The diode features a tight voltage tolerance of ±5%, ensuring accurate voltage regulation within its specified operating range. It can reliably function within a wide temperature range from -55°C up to 150°C, and meets the stringent automotive standard AEC-Q101, confirming its robustness for automotive and industrial applications.

Its small form factor with a height of 0.47 mm and length of 1 mm enables compact PCB designs while maintaining high performance. The device exhibits a maximum reverse leakage current of only 4 μA and a maximum Zener impedance of 600 Ω, reducing power loss and increasing efficiency.

Applications include industrial electronics, automotive electronics, portable instrumentation, and any general purpose voltage regulation use requiring a stable 2.2 V reference. The diode is widely used in circuits requiring a reliable low-voltage reference in environmental extremes.

This diode uses a compact DFN1006BD-2 package suitable for surface mounting. It provides voltage regulation with a nominal Zener voltage of 2.2 V. The device supports a maximum power dissipation of 365 mW for efficient operation.

Test current is set at 50 μA making it ideal for low bias applications. The diode operates reliably within a temperature range of -55°C to 150°C. Maximum reverse leakage current is low at 4 μA ensuring minimal power loss.

It complies with automotive standard AEC-Q101 for reliability. The package height is 0.47 mm and length is 1 mm, allowing compact PCB layouts. The Zener voltage tolerance is ±5% with a maximum impedance of 600 Ω.

EnvMart offers this Nexperia BZX8850S-C2V2-QYL diode as a key part for electronic circuit design requiring stable voltage regulation with excellent reliability and compact size. Explore more components in the Zener Diodes category for your industrial and electronic applications.
