Abracon 13.56 MHz Crystal Unit 16pF Load Capacitance HC-49-US Through Hole Mount ABLS-13.560MHZ-10-R20-D-T

Abracon ABLS-13.560MHZ-10-R20-D-T Crystal Unit is a through hole mounted component engineered for precise frequency control at 13.56 MHz, suitable for electronic applications requiring high stability and reliability.

This crystal unit features a 16pF load capacitance and is housed in a robust HC-49-US package with dimensional specifications of 11.5 mm length, 4.7 mm width, and 4.2 mm height, enabling easy integration onto printed circuit boards.

The unit maintains excellent frequency accuracy with a tolerance of ±30 ppm and frequency stability of ±50 ppm, operating efficiently within a temperature range of 0°C to 70°C. Its series resistance of 50Ω minimizes signal loss, ensuring clean oscillation for critical electronic circuits.

Designed to comply with RoHS directives, this crystal unit offers lead-free construction, making it environmentally friendly and suitable for modern electronic manufacturing processes. The product is supplied on tape and reel packaging, facilitating high-speed automated assembly.

Ideal for use in computers, modems, microprocessors, and wireless communication devices, this crystal unit supports diverse industrial and commercial electronics applications. Through hole mount for reliable mechanical stability in assemblies.

Precision frequency control for sensitive electronic systems. Wide operating temperature range suitable for various environments. Compliant with international environmental standards. Convenient tape and reel packaging supporting mass production.

This product forms part of the Abracon ABLS series of crystal units noted for their quality and performance. Professionals in electronics design and manufacturing will find it advantageous in delivering stable clock signals and timing references.
