Renesas Electronics Bus Switch Single 8:1, 20-Pin TSSOP, LVTTL Logic QS3VH245PAG8
Specifications
| Country of Origin | India |
|---|---|
| Brand | Renesas Electronics |
| Height | 1mm |
| Length | 6.5mm |
| Model | QS3VH245PAG8 |
| Mount Type | Surface |
| Series | QS32XVH245 |
| Configuration | Single 8:1 |
| Maximum Operating Temperature | 85°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Pin Count | 20 |
| Maximum Supply Voltage | 3.6V |
| Logic Family | LVTTL |
| Minimum Supply Voltage | 2.3V |
| Maximum High Level Output Current | 120mA |
| Maximum Propagation Delay Time @ CL | 0.2ns |
| Maximum Quiescent Current | 4mA |
| Maximum On State Resistance | 8Ω |
| Bus Width | 8bit |
| ConfigurationSingle 8 | 1 |
| Single 8 | 1 |
| Renesas Electronics QS3VH245PAG8, Bus Switch, Single 8 | 1, 20-Pin TSSOP |
Key Features
- Features LVTTL logic family compatibility for control signals.
- Supports surface mount type with a compact 6.5mm length and 1mm height.
- Operates within a voltage range of 2.3V to 3.6V supply.
- Provides low maximum on-state resistance of 8 ohms for efficient signal switching.
- Offers a maximum propagation delay time of 0.2 nanoseconds at specified load capacitance.
- Operating temperature range from -40°C to 85°C ensures reliability in varied environments.
- Maximum high level output current of 120mA supports robust signal outputs.
- Designed for bidirectional data flow with near-zero delay and rail-to-rail switching capability.
Product Description
Renesas Electronics QS3VH245PAG8 is a high-performance bus switch device featuring a single 8:1 configuration and housed in a 20-pin TSSOP package. It belongs to the LVTTL logic family, enabling compatibility with low-voltage transistor-transistor logic signals. This surface mount component measures 6.5mm in length and 1mm in height, making it suitable for compact PCB designs.
The device operates between 2.3V and 3.6V supply voltages, with a maximum quiescent current of 4mA, offering efficient power consumption. The switch presents an on-state resistance of up to 8 ohms, facilitating minimal signal loss. Propagation delay is exceptionally low at 0.2 nanoseconds under specified load conditions, ensuring high-speed signal transfer without added latency.
With an operating temperature range from -40°C to 85°C, the QS3VH245PAG8 is designed to perform reliably across harsh industrial and commercial environments. It supports a maximum high level output current of 120mA and allows bidirectional data flow with near zero delay, suitable for applications requiring precise timing and signal integrity.
This bus switch is ideal for use in industrial automation, digital signal routing, communication systems, semiconductor devices, and other electronics applications where rapid switching of 8-bit data buses is critical. The TSSOP 20-pin package further complements compact and efficient PCB layouts.
Features LVTTL compatible control inputs for easy system integration. Enables rail-to-rail switching from 0 to 5 volts for signal compatibility. Maintains excellent on-resistance matching between channels for balanced signal paths.
Suitable for bidirectional data flow, enhancing circuit design flexibility. Compact footprint and surface mount package support automated PCB assembly.
