Texas Instruments CMOS Inverter Logic IC Schmitt Trigger Input 6-Element 14-Pin TSSOP SN74HC14PW

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments CMOS Inverter Logic IC Schmitt Trigger Input 6-Element 14-Pin TSSOP SN74HC14PW

Name: Texas Instruments CMOS Inverter Logic IC Schmitt Trigger Input 6-Element 14-Pin TSSOP SN74HC14PW
Brand: Texas Instruments
SKU: 392791
Price: 0.99 USD
Availability: InStock



Category Electronic Components Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Brand	Texas Instruments
Height	1.15mm
Length	5mm
Model	SN74HC14PW
Width	4.4mm
Mount Type	Surface
Compatibility	Input CMOS, Output CMOS
Series	SN74HC14
Input Type	Schmitt Trigger
Maximum Operating Temperature	85°C
Package Type	TSSOP
Minimum Operating Temperature	-40°C
Operating Voltage	2 to 6 V
Pin Count	14
Number of Elements per Chip	6
Maximum Supply Voltage	6V
Logic Family	HC
Logic Function	Inverter
Minimum Supply Voltage	2V
Maximum High Level Output Current	-5.2mA
Maximum Propagation Delay Time @ CL	155ns
Maximum Low Level Output Current	5.2mA

Key Features

Operates from 2V to 6V supply voltage.
Maximum propagation delay time of 155ns at CL.
Maximum high-level output current of -5.2mA and low-level output current of 5.2mA.
Compatible with input and output CMOS logic levels.
Wide operating temperature range from -40°C to 85°C.
Compact 14-pin TSSOP surface mount package measuring 5mm x 4.4mm x 1.15mm.
Logic function is inverter with Schmitt Trigger input for noise immunity.
Part of the 74HC14 series, suitable for high-speed CMOS applications.

Product Description

Texas Instruments SN74HC14PW is a high-speed CMOS logic IC featuring Schmitt Trigger inputs and 6 inverter elements integrated per chip. The device operates within a supply voltage range of 2V to 6V, making it suitable for a wide range of electronic applications requiring low power CMOS logic and enhanced noise immunity.

This 14-pin TSSOP packaged inverter IC offers robust performance with a maximum propagation delay of 155ns at the specified load capacitance, supporting efficient switching speeds. The maximum output currents are -5.2mA for high-level and 5.2mA for low-level outputs, which provide stable logic level transitions compatible with other CMOS devices.

Its wide operating temperature range from -40°C to 85°C makes it ideal for industrial and commercial applications exposed to varying environmental conditions. The compact TSSOP surface mount package dimensions (5mm length, 4.4mm width, and 1.15mm height) enable ease of integration into dense PCB layouts.

Being part of the 74HC14 series, this device leverages silicon gate CMOS technology to combine speed similar to LSTTL logic with the low power consumption of CMOS technology. The Schmitt Trigger input enhances signal integrity by rejecting noise and providing clean digital transitions, broadly used in signal conditioning, waveform shaping, and digital logic interfacing in industrial, laboratory, and manufacturing electronics.

Operates at low supply voltages for energy-efficient designs. Schmitt Trigger inputs boost noise immunity and signal stability. Six independent inverter gates per chip offer compact multi-function logic solutions. Surface mount TSSOP package supports modern PCB assembly processes.

Wide temperature operation suits harsh industrial environments.

Suitable for applications in industrial automation, control circuits, instrumentation, and embedded system designs. This logic IC ensures reliable performance for complex digital logic implementations requiring inverter functionality with enhanced signal integrity.
