Wurth Elektronik WR-PHD Series Bottom Entry Through Hole PCB Socket, 8-Contact, 1 Row, 2.54 mm Pitch, 3A 61300815721
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500V |
| Brand | Wurth Elektronik |
| Orientation | Bottom Entry |
| Current | 3A |
| Mount Type | Through Hole |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | PCB Socket |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Connector System | Board-to-Board |
Key Features
- This 8-contact socket features a 2.54 mm pitch for standard PCB spacing.
- Constructed with copper alloy contact material for durability and conductivity.
- Gold contact plating ensures superior corrosion resistance and low contact resistance.
- Supports current rating of 3A and voltage up to 500V.
- Designed for through-hole mounting with bottom entry orientation.
- Operates reliably between -40°C and 105°C temperature range.
- Endures up to 25 mating cycles to ensure long-lasting performance.
- RoHS compliant and UL Approved (E323964) to meet safety and environmental standards.
Product Description
Wurth Elektronik 61300815721 is a high-quality WR-PHD Series bottom entry through hole PCB socket featuring 8 contacts in a single row with 2.54 mm pitch. It is engineered for secure board-to-board connections in various electronic assemblies requiring robust and reliable contact performance.
Manufactured from copper alloy with gold plating, this socket offers enhanced corrosion resistance and electrical conductivity, supporting a maximum current of 3A and voltage up to 500V AC. Its through hole mounting and bottom entry orientation make it suitable for various PCB layouts and industrial electronics applications.
The operating temperature range from -40°C to 105°C ensures the socket performs well under diverse environmental conditions, making it ideal for industrial, laboratory, manufacturing, and electronic equipment use cases.
Designed to withstand 25 mating cycles, this socket guarantees durability and longevity in repeated connection scenarios. Its RoHS compliance and UL approval (E323964) certify adherence to environmental and safety standards.
This 8-contact socket features a 2.54 mm pitch for standard PCB spacing. Constructed with copper alloy contact material for durability and conductivity. Gold contact plating ensures superior corrosion resistance and low contact resistance.
Supports current rating of 3A and voltage up to 500V. Designed for through-hole mounting with bottom entry orientation. Operates reliably between -40°C and 105°C temperature range. Endures up to 25 mating cycles to ensure long-lasting performance.
RoHS compliant and UL Approved (E323964) to meet safety and environmental standards.
This Wurth Elektronik PCB Socket is suited for a wide range of industrial electronics, electronic components manufacturing, repair and prototyping, and other professional PCB assembly environments.
Discover more high-quality PCB connectors and related electronic components in our extensive catalog on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this PCB socket is 3A.
This model supports a voltage capacity of up to 500V.
The pitch size of the contacts in this socket is 2.54 mm.
It operates reliably within a temperature range of -40°C to 105°C.
This socket features 8 contacts arranged in a single row.
This socket is designed for through-hole mounting.
The contacts are constructed from copper alloy, providing good conductivity.
The contacts are gold plated, which enhances corrosion resistance and reduces contact resistance.
This socket is designed to withstand up to 25 mating cycles.
Yes, this PCB socket is RoHS compliant, ensuring it meets environmental standards.
This model features a bottom entry orientation for its connections.
It is UL Approved (E323964), certifying adherence to safety and environmental standards.
