Wurth Elektronik WR-PHD Series Angled PCB Socket, 7-Contact, 1 Row, 2.54 mm Pitch 613007143121
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Angled |
| Current | 3A |
| Mount Type | PCB |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 7 |
| Contact Gender | Female |
Key Features
- This PCB socket features 7 contacts with copper alloy material optimized for reliable conduction.
- The connector has a 2.54 mm pitch and a single row arrangement suitable for standard PCBs.
- It supports a current rating of 3A and a voltage rating of 250V.
- Constructed with Polybutylene Terephthalate housing material offering durability and stability.
- This angled socket orientation enables easy connection in compact PCB layouts.
- The contacts are plated with gold ensuring corrosion resistance and superior conductivity.
- Operating temperature ranges from -40°C to 105°C for varied environmental conditions.
- RoHS compliant and UL approved (E323964) ensuring safety and environmental standards.
Product Description
Wurth Elektronik 613007143121 is a highly reliable angled PCB socket in the WR-PHD Series featuring 7 female contacts in a single row with a 2.54 mm standard pitch. It is specifically designed for PCB mounting applications where durability and excellent electrical performance are required. The housing is made of Polybutylene Terephthalate, providing mechanical strength and resistance to environmental factors.
The socket supports a current capacity of 3A and voltage up to 250V, suitable for low power electronic applications and signal transmissions. Its gold-plated copper alloy contacts ensure minimal contact resistance and high conductivity, enhancing signal integrity and device lifespan.
This component is rated for operation across a broad temperature range of -40°C to 105°C, making it suitable for industrial, telecommunications, and consumer electronics environments. Featuring an angled orientation, the socket allows efficient routing and space management on PCBs.
Compliant with RoHS standards and UL listed (E323964), this socket meets rigorous safety and environmental regulations. It supports up to 25 mating cycles, ensuring longevity in iterative assembly or maintenance processes. The product is manufactured in Taiwan, noted for precision and quality in electronics manufacturing.
7 female contacts with copper alloy and gold plating for durability and performance. 2.54 mm pitch with a single row, angled for versatile PCB layouts. Current rating of 3A and voltage rating of 250V for reliable electrical connections.
Polybutylene Terephthalate housing material ensures mechanical robustness. Wide operating temperature range from -40°C to 105°C for diverse use scenarios. RoHS compliant and UL approved (E323964) for safety and environmental compatibility.
Supports up to 25 mating cycles ensuring long service life. Manufactured in Taiwan, Province Of China, with consistent quality assurance.
This Wurth Elektronik WR-PHD Series angled PCB socket is ideal for electronics design, manufacturing, and repair applications requiring high-quality PCB connectors. Explore more PCB Sockets and connectors in the EnvMart catalogue for industrial, laboratory, and commercial electronics needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The socket supports a current rating of 3A, making it suitable for low power electronic applications and signal transmissions.
It has a voltage rating of 250V, allowing for reliable electrical connections in various applications.
The pitch size of this socket is 2.54 mm, which is standard for many PCB applications.
This socket features 7 female contacts arranged in a single row, designed for efficient PCB mounting.
The housing is constructed from Polybutylene Terephthalate, providing mechanical strength and stability.
It operates within a temperature range of -40°C to 105°C, making it suitable for diverse environmental conditions.
The contacts are made of copper alloy and are gold-plated, ensuring high conductivity and corrosion resistance.
Yes, this model is RoHS compliant, meeting environmental standards for hazardous substances.
This socket supports up to 25 mating cycles, ensuring longevity in assembly and maintenance processes.
The socket has an angled orientation, which allows for efficient routing in compact PCB layouts.
It is manufactured in Taiwan, known for its precision and quality in electronics manufacturing.
This model is UL approved (E323964) and compliant with RoHS standards, ensuring safety and environmental compatibility.
