Wurth Elektronik WR-PHD Series Straight Surface PCB Socket, 8-Contact, 2 Row, 2.54 mm Pitch 61000821821

Wurth Elektronik model 61000821821 is a high-quality WR-PHD Series PCB Socket featuring a straight surface mount design. It comprises 8 contacts arranged in 2 rows with a 2.54 mm pitch, making it ideal for compact and reliable board-to-board interconnections.

The socket's contacts are made from copper alloy and plated with gold to ensure excellent electrical conductivity and long-term resistance to corrosion. It supports a current capacity of up to 3A and a maximum voltage rating of 500V, suitable for various electronic applications.

Its insulator is produced from PA9T material, classified as UL94 V-0 for flame retardancy, which is critical for safety in industrial and commercial electronics. The operating temperature range from -40°C to 125°C allows for use in harsh environmental conditions without degradation.

The socket is designed for surface mounting technology on printed circuit boards, enhancing manufacturing efficiency. It provides a board-to-board connection system oriented straight for easy integration into different assembly layouts.

Constructed with copper alloy contact material for reliable conductivity. Gold plating enhances contact durability and corrosion resistance. Operates safely at voltages up to 500V. Designed to withstand temperatures ranging from -40°C to 125°C.

Supports a current rating of 3A for moderate electrical loads. Durability tested for 25 mating cycles ensuring consistent performance. Includes PA9T insulator material rated UL94 V-0 for flame retardancy. Board-to-board connector system oriented straight for ease of installation.

Surface mount type suitable for SMT processes in electronics manufacturing.

This PCB Socket is well-suited for use in electronic manufacturing industries, including industrial tools, laboratory equipment, HVAC systems, and communication devices where reliable and durable electrical connections are required. Its compliance with RoHS and lead-free standards supports environmentally responsible production.
