Samtec UPS Series Vertical Through Hole PCB Socket, 4-Contact, 1 Row, 3.81 mm Pitch, Solder Termination UPS-04-07.0-01-L-V

Free Delivery in India | Lowest Global Shipping Charges

Samtec UPS Series Vertical Through Hole PCB Socket, 4-Contact, 1 Row, 3.81 mm Pitch, Solder Termination UPS-04-07.0-01-L-V

Name: Samtec UPS Series Vertical Through Hole PCB Socket, 4-Contact, 1 Row, 3.81 mm Pitch, Solder Termination UPS-04-07.0-01-L-V
Brand: Samtec
SKU: 172485
Price: 7.01 USD
Availability: InStock



Category PCB Socket Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	620V
Brand	Samtec
Orientation	Vertical
Current	20A
Model	UPS-04-07.0-01-L-V
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Beryllium Copper Alloy
Series	UPS
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Socket
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	3.81mm
Standards/Approvals	RoHS
Contact Plating	Phosphor Bronze
Number of Contacts	4
Contact Gender	Female
Connector System	Board-to-Board

Key Features

The socket uses a solder termination type for secure PCB mounting.
Current rating is 20A, suitable for high-power applications.
Housing is constructed from liquid crystal polymer ensuring durability.
Designed for board-to-board connector system with female contact gender.
Operates reliably in temperatures ranging from -55°C to 125°C.
Contact material is beryllium copper alloy with phosphor bronze plating for excellent conductivity and corrosion resistance.
The orientation is vertical, facilitating compact and effective PCB layouts.
Compliance with RoHS standards ensures environmental safety and quality assurance.

Product Description

Samtec UPS-04-07.0-01-L-V is a high-quality vertical through hole PCB socket designed for electronics components assembly and power connectors applications. This model features 4 female contacts arranged in a single row with a precise 3.81 mm pitch, allowing reliable and compact board-to-board connections.

The socket termination is solder type, providing robust mechanical and electrical connection to PCBs. Constructed with a durable liquid crystal polymer housing, it offers excellent resistance to heat and mechanical stress.

Contact elements are made from beryllium copper alloy and plated with phosphor bronze to ensure high conductivity and resistance to corrosion during operation. This PCB Socket supports currents up to 20A and operates at voltages up to 620V, making it suitable for demanding industrial and electronic applications.

Designed for vertical orientation, it aids efficient PCB layout and space management. The component meets RoHS standards, ensuring compliance with environmental safety regulations. The socket uses a solder termination type for secure PCB mounting.

Current rating is 20A, suitable for high-power applications. Housing is constructed from liquid crystal polymer ensuring durability. Designed for board-to-board connector system with female contact gender. Operates reliably in temperatures ranging from -55°C to 125°C.

Contact material is beryllium copper alloy with phosphor bronze plating for excellent conductivity and corrosion resistance. Rated voltage is 620V accommodating demanding electrical environments. The orientation is vertical, facilitating compact and effective PCB layouts.

Compliance with RoHS standards ensures environmental safety and quality assurance. This Samtec UPS series socket is ideal for industrial, electronic manufacturing, and power connector applications requiring reliable and durable PCB connections.
