Samtec SEAM Series Horizontal Surface PCB Header, 30 Contact(s), 1.27 mm Pitch, 6 Row, Shrouded SEAM-30-02.0-L-06-2-A-K-TR

Samtec SEAM-30-02.0-L-06-2-A-K-TR is a high-quality horizontal surface-mount PCB header designed for board-to-board connector systems. It features 30 male copper alloy contacts configured in 6 rows with a 1.27 mm pitch, suitable for high density electronic assemblies.

The housing material is liquid crystal polymer, providing excellent mechanical strength and thermal stability. The contacts are plated with selective gold of 0.000254 mm thickness in the contact area and matte tin on the tails, ensuring reliable conductivity and solderability.

This shrouded connector is rated for 2.7 amperes current and 240 volts, withstanding a wide operating temperature range from -55°C to 125°C, making it appropriate for industrial, commercial, and laboratory electronic equipment.

Additional features include lead-free solder terminations meeting current environmental standards, alignment pins for precise mating, and polyimide film pick-and-place pads to facilitate automated assembly processes.

The product is supplied on tape and reel packaging to support high-volume manufacturing and efficient handling. Rated for a current capacity of 2.7A ensuring stable electrical performance. Constructed with a liquid crystal polymer housing for durability and thermal resistance.

Contacts are made from copper alloy with silver and tin plating for corrosion resistance. Designed for horizontal orientation and surface mount applications. Operates reliably within -55°C to 125°C temperature range. Supports a voltage rating of 240V suitable for various electronic applications.

Incorporates lead-free solder termination promoting environmental safety. Package includes alignment pin and polyimide film pick-and-place pad for automated assembly. Supplied in tape and reel packaging for streamlined manufacturing integration.

Ideal for electronics manufacturing, industrial equipment, telecommunications, and consumer device applications requiring reliable, high-density PCB connectors. Explore the comprehensive range of PCB Headers and connectors on EnvMart for advanced electronic component solutions.
