Samtec TSM Series Vertical Surface Mount Unshrouded Pin Header 72 Contacts 2 Rows 2.54 mm Pitch TSM-136-02-S-DV

Samtec TSM-136-02-S-DV is a vertical surface mount pin header connector designed for high-density PCB interconnections in industrial and electronic applications. With 72 contacts positioned in two parallel rows at a standard 2.54 mm pitch, this unshrouded header provides a reliable board-to-board connection method.

The housing is molded from black liquid crystal polymer, offering excellent mechanical strength and thermal stability essential for harsh operating conditions. Contacts are made from phosphor bronze material, plated with 0.76 micron gold on the posts for enhanced conductivity and corrosion resistance, and matte tin on the tails for superb solderability.

This connector supports operating temperatures ranging from -55°C to +125°C, ensuring dependable performance in diverse environments. It is rated for 475 volts AC, allowing it to handle standard industrial voltages safely. The termination style is solder type, enabling robust attachment onto printed circuit boards.

The unshrouded design allows greater accessibility and flexibility when pairing with corresponding connector components. Male contact gender suits board-to-board systems commonly used in electronic manufacturing, telecommunications, industrial controls, and computer hardware assembly.

Key use cases include high-density electronic assemblies, industrial control modules, instrumentation equipment, and consumer electronics requiring durable, precise pin header connections. Due to its high contact count and standard pitch, the TSM-136-02-S-DV is ideal for applications demanding reliable electrical interconnectivity with robust thermal performance.

Features vertical orientation for optimal surface mounting. Constructed with high-quality phosphor bronze contacts plated with 0.76 μm gold on post and matte tin on tail. Black liquid crystal polymer housing ensures excellent durability and thermal performance.

Unshrouded design enables flexible applications and easy mating. Operates reliably within temperature ranges from -55°C to 125°C. Rated for voltage up to 475V AC ensuring industrial strength performance. Designed for solder termination type facilitating secure attachment to PCBs.

Includes male contact gender suitable for board-to-board connector systems. Complies with no specific standards or approvals but built to industry-grade quality. Explore a wide range of PCB Headers and connectors in the Electronics Components category on EnvMart for all your industrial and commercial electronic assembly needs.
