Samtec Through Hole Pin Header 32 Contacts 2 Row 2.54 mm Pitch Glass Filled Polyester Housing Male Gold TSW-116-14-G-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-116-14-G-D |
| Mount Type | Through Hole |
| Special Features | Many options fo |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 32 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Manufactured with durable glass filled polyester housing for high structural integrity.
- Male contact pins made of phosphor bronze with gold plating for excellent conductivity and corrosion resistance.
- Unshrouded design allows easy soldering and inspection of pins.
- Supports operating temperature range from -55°C to 125°C for versatile industrial applications.
- Rated for voltage up to 550 volts ensuring reliable power and signal transfer.
- Through-hole mount with solder termination provides secure mechanical stability.
- Vertical orientation with 2.54 mm pitch and 32 contacts arranged in 2 rows.
Product Description
Samtec TSW-116-14-G-D is a high-quality through hole pin header designed for reliable board-to-board connections in industrial, electronic manufacturing, and quality control applications.
It features 32 male contacts arranged in 2 rows with a standard 2.54 mm (0.100 inch) pitch, providing consistent spacing compatible with a wide range of printed circuit boards. The housing is made from glass filled polyester, delivering mechanical strength and thermal stability under demanding operating conditions.
The contact pins utilize phosphor bronze material with gold plating, ensuring excellent electrical conductivity, durability, and resistance to oxidation. This unshrouded connector allows easy access for soldering and inspection. It supports a wide thermal range from -55°C up to 125°C, enabling use in harsh environments.
Rated for up to 550 volts, the TSW-116-14-G-D ensures safe and effective transmission of signals and power across electronic components. The solder termination and through-hole mount style provide secure mechanical retention on printed circuit boards.
Durable glass filled polyester housing enhances mechanical and thermal performance. Phosphor bronze contacts with gold plating optimize conductivity and corrosion protection. Unshrouded form factor enables straightforward assembly and maintenance.
Wide operating temperature range suits industrial and commercial use. High voltage rating supports flexible electronic design requirements. Through-hole solder termination secures the header firmly to the PCB. This connector is ideal for electronics manufacturers, OEMs, and repair facilities requiring dependable, standardized PCB connectors.
Explore more connectors and electronic components from Samtec by browsing the EnvMart Electronics & Electricals category.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a voltage of up to 550 volts, ensuring reliable power and signal transfer.
It supports an operating temperature range from -55°C to 125°C, making it suitable for various industrial applications.
This unit features 32 male contacts arranged in 2 rows, with a standard pitch of 2.54 mm.
The contact pins are made of phosphor bronze with gold plating, while the housing is constructed from glass filled polyester.
It utilizes a through-hole solder termination, providing secure mechanical stability on printed circuit boards.
This model is unshrouded, allowing for easy soldering and inspection of the pins.
The orientation of this connector is straight, which is typical for through-hole mounting applications.
It is designed for board-to-board connections, facilitating reliable connections between printed circuit boards.
The contacts are spaced at a pitch of 2.54 mm (0.100 inch), which is a standard spacing for many PCB applications.
The country of origin for this product is India.
It offers many options for customization, allowing for various configurations to meet specific application needs.
The contact system features a .025" (0.635 mm) square post design, ensuring compatibility with standard PCB layouts.
