Samtec SSA Series Straight Through Hole PCB Socket 5-Contact 1 Row 2.54 mm Pitch SSA-105-S-G

Free Delivery in India | Lowest Global Shipping Charges

Samtec SSA Series Straight Through Hole PCB Socket 5-Contact 1 Row 2.54 mm Pitch SSA-105-S-G

Name: Samtec SSA Series Straight Through Hole PCB Socket 5-Contact 1 Row 2.54 mm Pitch SSA-105-S-G
Brand: Samtec
SKU: 166720
Price: 1.52 USD
Availability: InStock



Category PCB Socket Brand Samtec Condition New

Specifications

Country of Origin	India
Brand	Samtec
Orientation	Straight
Model	SSA-105-S-G
Mount Type	Through Hole
Housing Material	Polyester
Contact Material	Phosphor Bronze
Series	SSA
Termination Type	Through Hole
Maximum Operating Temperature	125°C
Sub Type	Cost-Effective Socket Strip
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Standards/Approvals	RoHS
Contact Plating	Gold
Number of Contacts	5
Contact Gender	Female
Connector System	Board-to-Board

Key Features

Constructed with black PET polyester housing with UL 94V-O flammability rating.
Contacts are gold plated with 0.25 μm thickness for optimal conductivity.
Phosphor bronze contact material ensures durability and corrosion resistance.
Operates reliably between -55°C and 125°C temperature range.
Designed for through hole mounting with female contact gender.
Offers insulation resistance minimum of 5000 MΩ and voltage rating of 1000 VRMS.
Cost-effective socket strip ideal for electronic component board assemblies.

Product Description

Samtec SSA-105-S-G is a high-quality straight through hole PCB socket from the SSA series, designed for board-to-board connector systems in electronic assemblies. This cost-effective socket strip features 5 contacts arranged in a single row with a 2.54 mm pitch, ensuring precise mating and secure connections.

The socket housing is made of durable black PET polyester that meets UL 94V-O flammability standards, providing reliable insulation and safety in various industrial environments. Contacts are manufactured from phosphor bronze material and plated with 0.25 μm of gold to guarantee excellent electrical conductivity and long-term corrosion resistance.

It operates effectively over a wide temperature range, from -55°C to 125°C, making it suitable for demanding industrial, laboratory, and electronic manufacturing applications. The through hole termination type and female contact gender facilitate soldered PCB mountings with strong mechanical stability.

Technical features of the SSA-105-S-G include an insulation resistance of at least 5000 MΩ and a voltage rating of 1000 VRMS, ensuring safe and reliable operation under electrical stress.

This PCB socket is perfect for use in industrial electronics, control systems, instrumentation, and embedded device applications where dependable connectors with high contact integrity are required.

Black PET polyester housing with UL 94V-O rating. 5 gold-plated phosphor bronze contacts for optimal conductivity. Single row, 2.54 mm pitch design for standard PCB layouts. Wide operating temperature range from -55°C to 125°C.

Through hole termination for robust PCB mounting. Female contact gender, board-to-board connector system. Voltage rating of 1000 VRMS and insulation resistance ≥ 5000 MΩ. Cost-effective solution for electronic component assemblies.
