Texas Instruments Line Transceiver, Differential Bus Transceiver, Differential Input/Output, Non-Inverting SN65ALS176D

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments Line Transceiver, Differential Bus Transceiver, Differential Input/Output, Non-Inverting SN65ALS176D

Name: Texas Instruments Line Transceiver, Differential Bus Transceiver, Differential Input/Output, Non-Inverting SN65ALS176D
Brand: Texas Instruments
SKU: 166226
Price: 4.46 USD
Availability: InStock



Category Line Interface ICs Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Brand	Texas Instruments
Height	1.75mm
Length	5mm
Model	SN65ALS176D
Width	4mm
Mount Type	Surface
Output type	Differential
Series	SN65ALS176
Input Type	Differential
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Polarity	Non-Inverting
IC Type	Line Transceiver
Number Of Channels	1
Pin Count	8
Maximum Supply Voltage	5.25V
Logic Family	SN65
Logic Function	Differential Bus Transceiver
Minimum Supply Voltage	4.75V
Maximum High Level Output Current	-60mA
Maximum Propagation Delay Time @ CL	25ns
Supply Current	30mA
Maximum Low Level Output Current	60mA

Key Features

The device features one channel for differential signal transmission.
It supports a supply current of 30mA and maximum output currents of ±60mA.
The propagation delay time at typical load capacitance is 25ns, enabling high-speed data communication.
Designed for surface mount applications with a compact SOIC package for ease of PCB integration.
Operational temperature range from -40°C to 85°C ensures reliable performance in harsh environments.
No automotive standards or special approvals are applicable to this model.

Product Description

Texas Instruments SN65ALS176D Line Transceiver is a high-speed differential bus transceiver designed to facilitate reliable data transmission in electronic communication systems. It operates within a supply voltage range of 4.75V to 5.25V with a supply current of 30mA, making it efficient for power-sensitive applications.

This 8-pin SOIC surface mount device offers one channel for differential input and output, featuring a non-inverting polarity. The maximum output current ratings are ±60mA, ensuring robust signal driving capability. The typical signal propagation delay of 25ns at the rated load capacitance supports high data rates up to 10 Mbit/s or greater.

The device is suitable for industrial, communication, and networking applications where reliable line interface ICs are required. Its operational temperature range from -40°C to 85°C allows it to perform effectively over a wide temperature spectrum, ideal for both commercial and industrial electronics.

Measuring 5mm in length, 4mm in width, and 1.75mm in height, the compact SOIC package facilitates easy PCB layout for space-constrained environments. As part of the SN65ALS176 series, this line transceiver excludes automotive standards and special certifications, focusing on core functionality for differential line driving.

One differential channel for high-speed communication. Surface mount 8-pin SOIC package for compact design. Operating voltage range between 4.75V and 5.25V. Supply current of 30mA for efficient operation. Propagation delay time of 25ns at standard conditions.

Wide operating temperature range from -40°C to 85°C. Dimensions suitable for dense electronic assemblies.

This Texas Instruments transceiver is ideal for electronic component manufacturers, systems integrators, and repair technicians requiring reliable Line Interface ICs for embedded communication solutions. Explore more in the Semiconductors category on EnvMart for comprehensive electronic device selections.
