Texas Instruments Operational Amplifier 2-Channel 8-Pin SOIC 5-30V 700 kHz LM358DR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | LM358DR |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | LM358 |
| Output Current | -30mA |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Maximum Supply Voltage | 30V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 700kHz |
| Input Bias Current | -250 nA |
| Vos - Input Offset Voltage | 7 mV |
| Slew Rate | 0.3V/μs |
| Input Offset Current | 50 nA |
Key Features
- Offers two channels in a compact 8-pin SOIC surface mount package.
- Wide supply voltage range from 5V minimum to 30V maximum.
- Gain bandwidth product of 700 kHz suitable for general-purpose amplification.
- Low input bias current of -250 nA and input offset current of 50 nA.
- Input offset voltage of 7 mV and slew rate of 0.3 V/μs for precise signal handling.
- Operating temperature range from 0°C up to 70°C for reliable performance.
- Complies with RoHS standards ensuring environmentally friendly manufacturing.
Product Description
Texas Instruments LM358DR is a dual-channel operational amplifier designed for a wide range of general-purpose amplification needs in electronics and semiconductor applications. Packaged in an 8-Pin SOIC surface mount format, this device supports a supply voltage range from 5 V to 30 V, making it suitable for various circuit designs.
This operational amplifier features a gain bandwidth product of 700 kHz, providing adequate performance for many analog signal processing applications. Its low input bias current of -250 nA and input offset current of 50 nA ensure signal integrity and minimize error in amplification.
The input offset voltage of 7 mV and a slew rate of 0.3 V/μs deliver precise control over signal response, while the device’s thermal specifications allow operation in a temperature range from 0°C to 70°C, enabling use in typical industrial and commercial environments.
Dimensions are compact for seamless integration on printed circuit boards, measuring 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height. The SOIC packaging supports surface mounting technology, facilitating automated assembly processes.
This model complies with RoHS requirements, ensuring it meets international standards for removal of hazardous substances. The LM358 series from Texas Instruments is widely recognized for cost-effective performance in non-specialized applications, available in various configurations including single, dual, and quad packages.
Offers two channels in a compact 8-pin SOIC surface mount package. Wide supply voltage range from 5V minimum to 30V maximum. Gain bandwidth product of 700 kHz suitable for general-purpose amplification. Low input bias current of -250 nA and input offset current of 50 nA.
Input offset voltage of 7 mV and slew rate of 0.3 V/μs for precise signal handling. Operating temperature range from 0°C up to 70°C for reliable performance. Complies with RoHS standards ensuring environmentally friendly manufacturing.
Dimensions optimized for PCB surface mounting: 4.9 mm length, 3.91 mm width, 1.58 mm height.
This Texas Instruments operational amplifier is ideal for industrial, laboratory, manufacturing, and general electronic equipment applications. It provides reliable analog signal amplification in power management, audio signal processing, and sensor interfacing tasks. Explore more Operational Amplifiers and semiconductor components on EnvMart for wide technology solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LM358DR operates within a supply voltage range of 5V minimum to 30V maximum.
It features a gain bandwidth product of 700 kHz, suitable for general-purpose amplification.
This operational amplifier measures 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height.
The input bias current is -250 nA, which helps maintain signal integrity.
The input offset voltage for the LM358DR is 7 mV.
It can operate in a temperature range from 0°C to 70°C.
The slew rate is specified at 0.3 V/μs, allowing for precise signal handling.
This operational amplifier features two channels.
It is packaged in an 8-pin SOIC surface mount format.
This model complies with RoHS standards, ensuring it meets environmental regulations for hazardous substances.
The maximum output current is -30 mA.
It is suitable for general electronic equipment applications, including power management, audio signal processing, and sensor interfacing.
