Wurth Elektronik WR-PHD Jumper Straight Female Red Open Top 2 Way 1 Row 200V 1A 60900213521

Wurth Elektronik 60900213521 WR-PHD Jumper Straight Female Red Open Top is a high-quality electronic jumper connector designed for reliable board-to-board electrical connections in industrial and electronic applications. Rated for 200 volts and 1 ampere current, this jumper features a durable polybutylene terephthalate housing which provides excellent insulation with a UL94-V0 beige rating. Its compact dimensions (4.05mm length, 3.5mm depth, and 1.9mm width) make it suitable for use in tight circuit layouts, contributing to efficient PCB assembly.

This jumper is designed with a red color and open top configuration, incorporating 2 gold-plated copper alloy contacts to ensure corrosion resistance and reliable conductivity. The contact resistance is kept low at a maximum of 30 milliohms to maintain signal quality. The connector orientation is straight, and it supports a single row with a 2.54mm pitch, making it compatible with a variety of PCB connector layouts.

The model supports up to 25 mating cycles, demonstrating durability in multiple insertion/removal scenarios. It operates efficiently across a wide temperature range from -40°C to +125°C, suitable for industrial, manufacturing, and electronic testing environments. Its female connector gender ensures compatibility with corresponding male pins for secure connections.

This jumper is RoHS compliant and manufactured in Taiwan, Province Of China, adhering to environmental and quality standards. Its series designation is WR-PHD, reflecting a tested and well-known product line from Wurth Elektronik.

Typical applications for this jumper include industrial automation systems, electronic component assembly, power connectors in electronic circuits, and test connectors used in laboratory and research settings. It is ideal for PCB connectors & wire housings, specifically in jumpers and shunts category.

Operates at 200V and 1A current capacity. Durable polybutylene terephthalate housing with UL94-V0 rating. Compact size: 4.05mm (L) x 3.5mm (D) x 1.9mm (W). Gold plated copper alloy contacts for reliable contact. Straight orientation, single row with 2 contacts.

Supports 25 mating cycles with low contact resistance. Wide operating temperature: -40°C to +125°C. Red color with female connector gender, open top subtype. RoHS compliant and manufactured in Taiwan, Province Of China. Explore more electronic components and jumper connectors in the Electronics & Electricals category of EnvMart for tailored industrial and laboratory applications.
