Nexperia 13 V 500 mW Voltage Regulator Zener Diode Single Through Hole 2-Pin SOD-27 BZX79-C13,113

The Nexperia BZX79-C13,113 Zener Diode is a robust and precise semiconductor device designed for voltage regulation applications. Featuring a nominal Zener voltage of 13 V and a maximum power dissipation rating of 500 mW, this diode is optimized for stable voltage control in electronic circuits within industrial, laboratory, and electronic assembly contexts.

It employs a single diode configuration with a through-hole SOD-27 package, featuring two pins for reliable mounting and connectivity. The device specifications include a ±5% voltage tolerance, making it suitable for circuits requiring precise voltage thresholds. Its maximum operating temperature of 200°C ensures performance stability in elevated thermal environments.

The diode's compact dimensions (4.25 mm length and 1.85 mm height) enable integration into space-constrained electronic devices. Additionally, the device exhibits a low maximum reverse leakage current of 100 nA, minimizing current losses and enhancing overall circuit efficiency. The typical voltage temperature coefficient of 9.4 mV/°C contributes to consistent voltage regulation across varying ambient temperatures.

With a test current of 5 mA and maximum zener impedance of 30 Ω, the diode offers optimized performance under standard test conditions. Its through-hole mounting type provides mechanical stability for prototyping and durable device assemblies. The product does not carry automotive standard certification, aligning with general industrial semiconductor use.

Applications for the Nexperia BZX79-C13,113 include industrial electronic circuits, power supplies, instrumentation, and control systems requiring precise voltage regulation and reliable diode characteristics. Its construction and rating make it well-suited for uses in manufacturing, laboratory instrumentation, and industrial automation equipment.

This product is part of the BZX79 series from Nexperia, known for quality and dependable semiconductor performance. Utilizes single diode configuration suitable for voltage regulation applications. Voltage tolerance of ±5% ensures precision in voltage stabilization.

Maximum operating temperature of 200°C supports high thermal endurance. Compact dimension with length of 4.25mm and height of 1.85mm for space-efficient designs. Low maximum reverse leakage current of 100nA enhances circuit reliability.

Typical voltage temperature coefficient of 9.4mV/°C maintains stable voltage over temperature ranges. Test current specified at 5mA, optimizing device performance under standard conditions. High zener impedance capped at 30Ω minimizes voltage drop and power loss.

Robust through-hole mounting type ideal for durable board assembly. Constructed to meet BZX79 series performance standards without automotive-specific certifications.
