Nexperia 1.30 V 300 mW 5% Zener Diode Single Surface Mount 2-Pin UMD BZX384-C30,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 1.30 V 300 mW 5% Zener Diode Single Surface Mount 2-Pin UMD BZX384-C30,115

Name: Nexperia 1.30 V 300 mW 5% Zener Diode Single Surface Mount 2-Pin UMD BZX384-C30,115
Brand: Nexperia
SKU: 164500
Price: 0.06 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.1mm
Length	2.7mm
Model	BZX384-C30,115
Mount Type	Surface
Series	BZX384
Maximum Operating Temperature	150°C
Package Type	UMD
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	300mW
Diode Configuration	Single
Test Current It	2mA
Maximum Reverse Leakage Current	50nA
Nominal Zener Voltage Vz	30V
Zener Type	Voltage Regulator
Maximum Zener Impedance	80Ω
Typical Voltage Temperature Coefficient	26.6mV/°C
Surface Mount case	SOD-323 (SC-76)
Diodes Inc, 24V Zener Diode 2.5% 500 mW SMT 2-Pin SOD-323FBrand	DiodesZetex

Key Features

The diode has a nominal Zener voltage of 30 V with ±5% tolerance.
It supports a maximum power dissipation of 300 mW in a compact surface mount package.
The 2-pin diode features a SOD-323 (SC-76) surface mount case suitable for automated assembly.
Operating temperature range extends from -65°C to 150°C for robust performance.
The device meets automotive quality standard AEC-Q101.
Maximum reverse leakage current is only 50 nA, ensuring low standby power loss.
Maximum Zener impedance is 80 Ω providing stable voltage regulation.
Typical voltage temperature coefficient is 26.6 mV/°C ensuring predictable behavior with temperature changes.

Product Description

Nexperia BZX384-C30,115 is a precision 30 V Zener diode designed for voltage regulation and overvoltage protection in electronic circuits. The diode is a single element device housed in a surface mount SOD-323 (SC-76) 2-pin UMD package, enabling compact and reliable PCB assembly.

With a maximum power dissipation of 300 mW, it provides stable voltage regulation at a test current of 2 mA. The nominal Zener voltage of 30 V features a tolerance of ±5%, making it suitable for applications requiring moderate voltage accuracy.

This diode operates reliably over a wide temperature range from -65°C to 150°C, complying with automotive standard AEC-Q101 for quality and durability in harsh environments.

The device exhibits low maximum reverse leakage current of 50 nA and a maximum Zener impedance of 80 Ω, which ensures minimal power waste and stable voltage output during operation. Its compact dimensions of 1.1 mm height and 2.7 mm length facilitate usage in space-constrained electronic assemblies.

The diode configuration is single element. Mount type is surface mount for automated SMT assembly. Typical voltage temperature coefficient is 26.6 mV/°C for temperature-dependent voltage stability. Package type is UMD, a standard SMD package.

This component is widely used in power supplies, voltage regulators, and protection circuits in industrial, automotive, and consumer electronics.

This Nexperia Zener diode is made in China and conforms to industry standards for quality and reliability. It is ideal for laboratory, manufacturing, and electronic repair use cases requiring reliable voltage regulation components.
